Beckhoff CP7202-0000-0060 CP72xx Series Economy Panel PC

Only 10 item(s) left in stock

Manufacturer: BECKHOFF
Product No.: CP7202-0000-0060
Country of origin:Германия
Product Type: Economy Panel PCs
Payment: T/T, Western Union
Weight: 5000g
Shipping port: Xiamen
Warranty: 12 months

Description

Designed for space-saving mounting arm installation, the Beckhoff CP7202-0000-0060 functions as a high-performance industrial PC platform that integrates robust computing with dynamic visual control. Constructed with a heavy-duty aluminum housing, this Economy Panel PC is engineered to mount directly on 48 mm tube systems from either the top or bottom, providing immediate field-level visualization without the need for a control cabinet. Passive heat dissipation via integrated heat sinks combined with an internal fan ensures optimal thermal management across all housing walls, guaranteeing system reliability in rigorous shop-floor environments.

Features

Robust aluminum housing designed specifically for mounting arm installation.
Compatible with Rittal and Rolec mounting arm systems using a 48 mm diameter tube.
Passive cooling design reinforced with an internal fan for heat distribution.
Flexible layout options for functional front laminates, touch screens, and keyboards.
Integrated SATA RAID 1 controller on-board for enhanced data security.

Applications

Automotive assembly line tracking and operation
Machine tool control and CNC visualization
Process monitoring in packaging and food production plants
Material handling and warehouse logistics interfaces

Technical Specifications

Manufacturer	Beckhoff
Model/Part Number	CP7202-0000-0060
Housing Material	Aluminum
Protection Rating	IP65
Operating Temperature	0 to 45 degC
Cooling System	Passive heat sink with internal fan
Processor	Intel Celeron G3900TE 2.3 GHz (2 cores)
Motherboard	3.5-inch motherboard (6th/7th generation Intel)
Memory	4 GB DDR4 RAM (expandable up to 32 GB)
Ethernet Ports	2 x 100/1000BASE-T on-board (1 led out as push-pull interface)
Power Supply Requirements	24 V DC
Storage Slots	1 x 2.5-inch HDD/SSD slot, 1 x CFast slot
Approximate Weight	5.0 kg

Installation Guidelines

Ensure a minimum clearance of 20 cm (7.9 inches) around the unit to facilitate necessary air circulation.
Verify that the mounting arm system is rated to safely support the 5.0 kg base weight of the Panel PC plus any connected cabling.
Seal any unused cable entry slots with standard IP65-rated blanks to maintain the environmental integrity of the enclosure.

Key Features:

#Beckhoff CP72xx #Economy Panel PCs

What is the protection rating of the Beckhoff CP7202-0000-0060?

The Panel PC features a full IP65 protection rating, making it completely protected against dust ingress and low-pressure water jets from all directions.

What are the mounting requirements for this Panel PC?

It is designed for mounting arm installation utilizing a rotatable adapter compatible with Rittal and Rolec mounting arm systems with a 48 mm tube from the top or bottom.

Does this unit require active external ventilation?

No. The system uses passive cooling through an integrated heat sink structure combined with an internal fan for heat distribution, though it requires a 20 cm clearance around the housing for air circulation.
