Omron H8PS-32BP Cam Positioner

Description

Designed for high-precision angle and position-based control, the Omron H8PS-32BP operates as a compact 1/4 DIN rotary cam positioner featuring 32 transistor outputs. This device replaces traditional mechanical cams in automated machinery, utilizing electronic encoder inputs to track angular position and execute precise output timing. The integrated DIP switch configuration enables rapid field selection of encoder rotation direction, accommodating both forward (CW) and reverse (CCW) operation without wiring modifications. Built with a clear, back-lit LCD screen, operators can easily monitor program steps and angular positions directly on the front panel.

Features

• Supports up to 32 PNP transistor output channels for multi-point timing control.
• Standard 1/4 DIN (96 x 96 mm) housing designed for clean front-panel integration.
• Back-lit LCD display provides high-visibility position and setup monitoring.
• Hardware-selectable encoder rotation direction (CW/CCW) via integrated DIP switches.
• Designed for rugged industrial environments requiring repeatable rotational synchronization.

Applications

• Packaging machinery and automated bagging systems.
• Food and beverage bottling and carton assembly.
• Press control and metal stamping processes.
• Rotary indexing tables and automated assembly lines.

Technical Specifications

Installation Guidelines

• Prepare a standard 1/4 DIN (96 x 96 mm) square cutout in the enclosure panel.
• Slide the unit through the cutout from the front and secure it with the provided mounting brackets.
• Ensure that all encoder and control wiring is shielded and routed away from high-voltage AC cables to minimize noise interference.
• Set the encoder rotation direction DIP switch to the desired orientation (CW/CCW) before applying control power to the unit.
• Verify that the operational supply voltage is within the specified range of 20.4 to 26.4 VAC.
