Schneider Electric ATV12HU15M3 Altivar 12 Frequenzumrichter

Description

The ATV12HU15M3 is a compact Altivar 12 variable frequency drive (VFD) engineered for the efficient speed and torque control of three-phase asynchronous motors. Rated for 1.5 kW (2 HP) and compatible with 200–240 V three-phase power supplies, this drive offers a user-friendly solution for small-scale industrial and commercial motor control applications. Its design prioritizes ease of setup, energy efficiency, and reliable performance, making it an excellent choice for modernizing equipment or implementing precise motor regulation in space-constrained environments.

Features

• Power Rating: 1.5 kW (2 HP) suitable for various small motor applications.
• Voltage Compatibility: Designed for 200–240 V three-phase power networks.
• Compact Footprint: 20 x 18 x 20 cm dimensions allow for efficient control cabinet utilization.
• Operational Flexibility: Intuitive programming and integration capabilities for diverse control needs.
• Energy Efficiency: Reduces power consumption by optimizing motor speed based on application demand.

Applications

• Small conveyor systems and material handling.
• HVAC fan and blower motors.
• Commercial pumps and centrifugal equipment.
• Packaging machinery and automated shop-floor equipment.

Technical Specifications

Installation Guidelines

• Mounting: Install vertically in a clean, ventilated enclosure to ensure proper heat dissipation. Maintain required clearances as specified in the manual.
• Wiring: Ensure motor and power cables are correctly sized and routed. Keep signal/control cables physically separated from power cables to prevent electromagnetic interference.
• Grounding: Establish a robust ground connection to the drive's protective earth terminal to ensure safety and improve electromagnetic compatibility.
• Commissioning: Use the integrated HMI or programming software to configure motor parameters, acceleration/deceleration ramps, and control logic according to the application requirements.
• Environment: Operate within the specified temperature and humidity limits to maintain the longevity and performance of the electronic components.
