The ABB 200-IE8 is an 8-channel analog input module for S200 I/O systems.
It supports voltage and current signals with 12-bit resolution for precise industrial data acquisition.
Moreover, galvanic isolation and individual input filtering ensure reliable signal integrity in automation applications.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Type | Analog Input Module |
| Model | 200-IE8 (S200 I/O Series) |
| Product Number / Order Code | 490176097 |
| Input Channels | 8 Single-ended Channels |
| Resolution | 12-Bit |
| Input Ranges | 0-10 V, ±10 V, 0-20 mA, 4-20 mA |
| Input Resistance | 200 kΩ (Voltage) / 238 Ω (Current) |
| Isolation Voltage | 850 V DC for 1s (Plant to System) |
| Backplane Key Code | 3 |
| Mechanical Configuration | Rack-mounted analog input module |
| Product Net Width | 94 mm |
| Product Net Height | 46 mm |
| Product Net Depth | 53 mm |
| Product Net Weight | 0.085 kg (excluding package) |
| Installation | Requires external 24 V DC and compatible terminal base (200-TB2/TB3) |
Industrial process control analog signal acquisition
Integration with Advant OCS, SattCon, and S200 I/O systems
High-density 8-channel analog input solutions
Precision voltage and current measurement in automation
Systems requiring galvanic isolation for signal integrity
Global Express Shipping
Returns & Warranty
Manufacturer: ABB
Product No.: S200-IE8
Country of origin:Sweden
Product Type: Analog Input Module
Barcode: 85371091
Payment: T/T, Western Union
Weight: 5540g
Dimensions: 94mm x 46mm x 53mm
Shipping port: Xiamen
Warranty: 12 months
