The ABB ACS550-01-012A-4 is a 3-phase low-voltage AC drive for general industrial motor control.
It delivers 5.5 kW output power with a rated current of 11.9 A and supports 380–480 V operation.
Moreover, it features IP21 protection, IE2 efficiency, and Frame Size R1 for compact, wall-mounted installation.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Type | General Purpose LV AC Drive |
| Model / Type Designation | ACS550-01-012A-4 |
| Product ID | 3AUA0000002420-D |
| Frame Size | R1 |
| Input Voltage | 3-phase 380–480 V |
| Normal Duty Power (Pn) | 5.5 kW, 11.9 A |
| Heavy-Duty Power (Phd) | 4 kW, 8.8 A |
| Frequency Range | 47.5–63 Hz |
| Protection Degree | IP21 / NEMA Type 1 |
| Efficiency Level | IE2 |
| Energy Efficiency | 97.2% at 90% frequency, 95.4% at 50% load |
| Absolute Loss at Full Load | 180 W |
| Mechanical Configuration | Wall-mounted enclosure |
| Dimensions (H × W × D) | 365 × 225 × 465 mm |
| Net Weight | 6.1 kg |
<ul> <li>Centrifugal pumps and fans</li> <li>Constant torque applications</li> <li>General machinery in industrial environments</li> <li>Wall-mounted compact installations</li> <li>Energy-efficient motor control systems</li> </ul>
Global Express Shipping
Returns & Warranty
Manufacturer: ABB
Product No.: ACS550-01-012A-4
Country of origin:Sweden
Product Type: General Purpose Wall-Mounted Drive
Barcode: 85044095
Payment: T/T, Western Union
Weight: 6500g
Dimensions: 12.50cm x 36.90cm x 21.20cm
Shipping port: Xiamen
Warranty: 12 months
