ABB HIEE305106R0001 UNS 0017A-P,V1 UNITROL 6000 Firing Board

SKU HIEE305106R0001 UNS0017A-P,V1

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: HIEE305106R0001 UNS0017A-P,V1
  • Origin Switzerland
  • Product Type: Firing Card
  • Barcode: 85372000
  • Payment: T/T, Western Union
  • Weight: 1.13 kg
  • Dimensions: 210 mm x 255 mm x 365 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Firing Boards UNITROL

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB HIEE305106R0001 UNS 0017A-P,V1 UNITROL 6000 Firing Board

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The ABB HIEE305106R0001 is a high-precision hardware assembly configured as the UNS 0017A-P,V1 firing board. Serving as the primary gate control interface within advanced static excitation systems, this firing unit generates exact electrical gate trigger pulses to modulate large thyristor bridges. The board converts reference control vectors from the main processing unit into perfectly synchronized high-current firing commands, ensuring optimal regulation of generator field currents. Engineered as a critical component for large synchronous machinery applications, the UNS 0017A-P,V1 delivers exceptional timing resolution and system safety isolation to safeguard internal logic networks from high-power field dynamics.

Features

  • Integrates specialized firing circuit logic for synchronous generator gate pulse control.
  • Designed to match the high-power performance profiles of large static excitation infrastructure.
  • Offered as a genuine new production assembly to maintain long-term industrial asset sustainability.

Applications

  • UNITROL 6000 X-power static excitation systems and related power electronics controllers.
  • Large-scale power generation infrastructure utilizing synchronous machines.

Technical Specifications

Parameter Specification
Manufacturer ABB
Product ID HIEE305106R0001
Model Designation UNS 0017A-P,V1 (UNS 0017A-P)
Module Type Firing Board (Firing Unit)
System Compatibility UNITROL 6000 X-power Systems
Country of Origin Switzerland
Customs Tariff Number 85372000
Product Net Weight 1.13 kg
Product Net Depth / Length 365 mm
Product Net Height 210 mm
Product Net Width 255 mm
Part Type New
Minimum Order Quantity 1 piece
WEEE Category Product Not in WEEE Scope

Installation Guidelines

  • Chassis Positioning: Ensure the host control bay is completely isolated from all main voltage feeds. Slide the card smoothly along the chassis card guides until the backplane connectors interface firmly.
  • ESD Mitigation Protocols: The integrated components on this firing card are highly sensitive to static discharge. Engineers must wear a grounded ESD wrist strap before handling, extracting, or installing the unit.
  • Connection Security: Fasten all retention screws and multi-pin terminal plugs tightly to avoid contact resistance, ensuring the gate leads are kept distinct from primary power busbars to mitigate interference.
  • Thermal Management: Verify that cabinet airflow paths and cooling fans are unobstructed to preserve stable timing patterns and prevent heat accumulation on the gate drive channels.
