ABB PP865A 3BSE042236R2 Panel 800 15" TFT Touch Panel

SKU 3BSE042236R2

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: 3BSE042236R2
  • Origin Switzerland
  • Product Type: Touch Panel
  • Barcode: 85371091
  • Payment: T/T, Western Union
  • Weight: 4.64 kg
  • Dimensions: 1024x768 pixels
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Advant DCS 800xA HMI Touch Panels
Quantità
Call sales Contact

Product Description

Description

The ABB PP865A is an industrial operator interface panel designed for process monitoring and control system interaction. It features a 15" TFT touch panel display with a resolution of 1024x768 pixels, supporting both high-resolution graphics and clear text in full color. This unit serves as a critical human-machine interface component within the Panel 800 series, enabling robust operations management. The PP865A requires Panel Builder 800 version 5 for configuration and project deployment. To safeguard the front screen display under harsh industrial conditions, the application of an RX865 Key Cover is recommended.

Features

  • High-resolution 15-inch TFT color touchscreen supporting text and graphics
  • Native resolution of 1024x768 pixels for clear operator visualization
  • Programmed and configured exclusively via Panel Builder 800 version 5 software
  • Native compatibility with ABB 800xA and Compact Product Suite operations
  • Optional physical protection compatibility via the RX865 Key Cover

Applications

  • System monitoring and operation in ABB 800xA distributed control system (DCS) architectures
  • Localized human-machine interface (HMI) for Compact Product Suite industrial applications
  • Factory automation and process visualization control rooms

Technical Specifications

Parameter Value
Manufacturer ABB
Model PP865A
Product ID 3BSE042236R2
Display Type 15" TFT Touch Panel
Resolution 1024x768 pixels
Display Capability Graphics & text, color
Required Configuration Software Panel Builder 800 version 5
Recommended Protection Accessory RX865 Key Cover
Product Net Weight 4.64 kg
Country of Origin Taiwan, Province Of China (TW)
Customs Tariff Number 85371091

Installation Guidelines

  • Panel Mounting: Ensure the cutout dimensions match the 15-inch enclosure specifications before securing the panel into the control cabinet door.
  • Front Protection: Install the optional RX865 Key Cover over the front interface if the environment is prone to mechanical scratching or heavy debris exposure.
  • Configuration Setup: Connect the unit to a engineering workstation equipped with Panel Builder 800 version 5 to load or update configuration profiles before deployment.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Which software is required to configure this operator panel?
The device requires Panel Builder 800 version 5 software for full configuration and visualization layout deployment.
What accessory is recommended to protect the display front?
It is recommended to use the RX865 Key Cover to protect the front face of the touch panel from physical wear and environmental hazards.
With which control systems is this touch panel categorized?
The panel is classified under ABB 800xA and Compact Product Suite system accessories, specifically within the Panel 800 product lines.
