ABB PP886 3BSE092980R1 Panel 800 Operator Panel

SKU PP886 3BSE092980R1

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: PP886 3BSE092980R1
Origin Taiwan
Product Type: Operator Panels
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 3.85 kg
Dimensions: 410 mm x 286 mm x 61 mm
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The ABB PP886 (Product ID: 3BSE092980R1) is a high-resolution touchscreen human-machine interface (HMI) designed to provide centralized process visualization, diagnostics, and machine-level control within industrial automation systems. This industrial operator panel features a 15.4-inch widescreen display with a 1280x800 resolution and a 16:10 aspect ratio, providing clear graphical replication of complex factory environments. Engineered as a direct mechanical and functional replacement for the legacy PP885 panel, the PP886 3BSE092980R1 integrates into various control architectures including System 800xA, Compact Product Suite, Freelance, and Symphony Plus. The device relies on a built-in lithium button cell battery to maintain real-time clock data and volatile memory registers during power interruptions. Configured through Panel Builder 800 Version 6.2 or higher, it offers robust interface communication across electrical monitoring and distribution panels.

Features

Widescreen 15.4-inch display providing sharp 1280x800 pixel resolution for multi-variable graphics tracking.
Native system compatibility across ABB System 800xA, Freelance, Compact Product Suite, and Symphony Plus architectures.
Backward compatibility serving as a standard mechanical replacement for the legacy PP885 panel.
Integrated hardware composition including a 2.5 g lithium button cell battery for memory and internal clock backup.
Robust structural build suited for electrical control or power distribution infrastructure environments.

Applications

Human-machine interface visualization in System 800xA and Compact Product Suite control frameworks.
Process monitoring and local machine oversight in power generation, chemical, and water utility networks.
Substation automation, electrical control panels, and medium-voltage distribution systems.

Ordering Information

Model Designation	Product ID	Catalog Description	Hardware Replaces
PP886	3BSE092980R1	PP886 Standard Panel 15"	PP885

Technical Specifications

Parameter	Specification
Manufacturer	ABB
Model Designation	PP886
Product ID	3BSE092980R1
Product Type	Control System Accessory / Operator Panel
Screen Size	15.4 in
Resolution	1280x800 widescreen (16:10)
Configuration Software	Requires Panel Builder 800 Version 6.2
Number of Batteries	1
Battery Chemical Composition	Lithium
Battery Type	Button Cell
Battery Weight	2.5 g
Product Net Width	410 mm
Product Net Height	286 mm
Product Net Depth / Length	61 mm
Product Net Weight	3.85 kg
Customs Tariff Number	85371010

Installation Guidelines

Panel Cutout Mounting: Insert the housing into a clean panel cutout matching the 410 mm x 286 mm structural boundaries, and tighten the integrated retaining clips to seal the front bezel against ingress.
Front Screen Protection: To preserve responsive touch interfaces in highly abrasive or oily environments, it is highly recommended to apply the optional RX886 touch cover.
Battery Service Handling: The unit incorporates a 2.5 g lithium button cell battery. Ensure the system power is switched off before replacing the cell, observing correct polarity alignment upon insertion.
Configuration Deployment: Ensure Panel Builder 800 Version 6.2 or later is installed on your workstation to compile and download runtime graphic projects to the panel.

Compliance and Certifications

Category	Standard / Directive
RoHS Information	Following EU Directive 2011/65/EU
WEEE Category	2. Screens, Monitors, and Equipment Containing Screens Having a Surface Greater Than 100 cm2
