The ABB REF601 is a dedicated feeder protection and control relay belonging to the Relion 605 Series. Designed for primary and secondary distribution networks, the REF601 provides protection, monitoring, and control functionality for utility and industrial power system overhead lines, cable feeders, and distribution transformers. It features an integrated local human-machine interface (LHMI) with built-in control buttons for single circuit breaker operation, support for conventional CTs or Rogowski current sensors, and serial communication capabilities.
| Parameter | Value |
|---|---|
| Manufacturer | ABB |
| Model | REF601 |
| Product Series | Relion 605 Series |
| Device Type | Feeder Protection and Control Relay |
| Analog Inputs (CT Version) | 4 CTs |
| Analog Inputs (Sensor Version) | 3 sensor inputs, 1 CT input (1 A for zero sequence/residual current) |
| Binary Inputs | 4 |
| Binary Outputs | 6 |
| Sequence of Events Storage | 100 events (1 ms resolution) |
| Fault Data Storage | Analog fault records for the last 5 trip events |
| Serial Communication Protocols | MODBUS RTU, IEC 60870-5-103 |
| Serial Interface | RS-485, 2-wire |
| Interface Type | Function / Assignment |
|---|---|
| RS-485 (2-wire) | Serial communication port supporting MODBUS RTU / IEC 60870-5-103 protocols |
| Analog Inputs | 4 CT inputs or 3 sensor inputs + 1 conventional CT input (1 A) |
| Binary I/O Terminals | 4 configurable binary inputs and 6 configurable binary outputs |
| Terminal Type | Detachable terminals with CT shorting |
