Allen-Bradley MPL-B4540F-MK74AA MP-Series Servo Motor

SKU MPL-B4540F-MK74AA

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: MPL-B4540F-MK74AA
  • Origin United States
  • Product Type: Servo Motors
  • Payment: T/T, Western Union
  • Weight: 10.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

MP-Series Servo Motors
Quantità
Call sales Contact

Product Description

Description

Engineered for high-performance motion control systems, the MPL-B4540F-MK74AA is a premium brushless servo motor belonging to the Allen-Bradley MP-Series Low Inertia family. This motor is designed to meet the rigorous demands of modern industrial automation, providing high torque output within a highly compact footprint. Equipped with a high-resolution feedback system, it delivers precise position and velocity data to compatible servo drives, ensuring seamless closed-loop control. The low-inertia rotor design allows for rapid acceleration and deceleration, making it highly suitable for applications requiring rapid, repetitive positioning cycles.

Features

  • Low-inertia rotor optimization for highly dynamic system responses.
  • High-resolution multi-turn absolute encoder for precise position tracking without homing sequences.
  • Compact 115 mm frame size maximizing machine mounting efficiency and power density.
  • Right-angle, rotatable circular DIN connectors for flexible cabling and simplified installation.
  • Keyless shaft extension to facilitate secure, high-speed mechanical coupling.
  • Rugged industrial housing designed to withstand standard factory floor environments.

Applications

  • Packaging and container labeling machinery
  • High-speed material handling and transfer lines
  • Automotive assembly systems and robotic positioning
  • Metal forming, cutting, and fabrication equipment
  • Electronic assembly and pick-and-place stations

Technical Specifications

Manufacturer Allen-Bradley / Rockwell Automation
Model Number MPL-B4540F-MK74AA
Series MP-Series Low Inertia
Voltage Class 460 V AC
Rated Speed 3000 RPM
Rated Output 2.6 kW
Rotor Inertia 0.00052 kg-m2
Frame Size 115 mm
Magnet Stack Length 4.0 in (approx. 101.6 mm)
Feedback Type Multi-turn high-resolution encoder
Shaft Design Keyless shaft
Brake Option No brake
Connectors Circular DIN, Right-angle, Rotatable
Shipping Weight 10 kg

Connections and Interfaces

Connector Type Function / Wiring Layout
Power Connector 4-pin circular DIN supplying motor phases (U, V, W) and protective ground.
Feedback Connector 17-pin circular DIN carrying absolute encoder signals and internal thermal switch connections.

Installation Guidelines

  • Shaft Alignment: Ensure precise alignment with the driven load coupling to prevent premature bearing wear and shaft fatigue.
  • Cable Routing: Utilize the rotatable design of the circular DIN connectors to route cables away from moving parts and sharp edges.
  • Thermal Management: Maintain unobstructed airflow around the motor housing to facilitate natural convection cooling. Do not cover the motor frame.
  • Grounding: Connect the motor's protective ground terminal to the common drive panel ground bus using low-impedance bonding straps.

Compliance and Certifications

  • CE Compliant
  • UL Listed
  • cUL Certified
  • RoHS Compliant
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the rated speed and output power of the MPL-B4540F-MK74AA?
The MPL-B4540F-MK74AA has a rated speed of 3000 RPM and a rated output power of 2.6 kW.
Does this model come equipped with an integrated holding brake?
No, this specific model (MPL-B4540F-MK74AA) does not include an integrated holding brake.
What feedback mechanism is used in the MPL-B4540F-MK74AA?
It features an integrated multi-turn high-resolution absolute encoder for accurate closed-loop position and speed feedback.
What is the frame size of this MP-Series motor?
This motor features a 115 mm frame size with a 4.0-inch magnet stack length.
