Designed for space-constrained control cabinet installations, the BECKHOFF C6015-0010 delivers high-performance processing in an exceptionally small footprint. This ultra-compact industrial PC leverages Intel Atom processors to execute demanding automation, visualization, and communication tasks directly at the machine level. Its robust, fanless design ensures long-term reliability in harsh industrial environments, making it an ideal hardware platform for TwinCAT-based control systems.
Featuring an aluminum zinc die-cast housing, the device is engineered for passive cooling via a single-side cooling plate. With dual on-board Gigabit Ethernet interfaces and versatile USB connectivity, the C6015-0010 integrates seamlessly into modern industrial networks, serving as an efficient edge gateway, controller, or decentralized data acquisition node.
| Manufacturer | BECKHOFF |
| Part Number/Model | C6015-0010 |
| Device Type | Ultra-compact control cabinet PC |
| Processor | Intel Atom E3815, 1.46 GHz, 1 core (Option: up to Intel Atom E3845 1.91 GHz, 4 cores) |
| Motherboard | Compact motherboard for Intel Atom E38xx |
| Memory | 2 GB DDR3L RAM (Option: up to 4 GB DDR3L RAM ex factory) |
| Graphic Adapter | Integrated in the processor |
| Storage | 40 GB M.2 SSD (Option: up to 160 GB M.2 SSD) |
| Ethernet Ports | 2 x 100/1000BASE-T on-board |
| Interfaces | 1 x USB 3.0, 1 x USB 2.0, 1 x DisplayPort |
| Power Supply | 24 V DC (Option: UPS) |
| Housing Material | Aluminum zinc die-cast |
| Protection Rating | IP20 |
| Operating Temperature | 0 to 55 degC |
| Dimensions (W x H x D) | 82 x 82 x 40 mm (3.2" x 3.2" x 1.6") without mounting plate |
| Weight | 2.0 kg (Shipping Weight) |
| Interface Port | Function / Specification |
|---|---|
| Ethernet 1 & 2 | 2 x RJ45 (100/1000BASE-T) for network connection and EtherCAT control |
| USB 3.0 | 1 x High-speed USB port for external storage or peripherals |
| USB 2.0 | 1 x Standard USB port for input devices or configuration tools |
| DisplayPort | 1 x Digital video output for HMI or external monitors |
| Power Input | 24 V DC terminal connection |
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: C6015-0010
Country of origin:Germany
Product Type: Industrial PCs
Payment: T/T, Western Union
Weight: 2000g
Dimensions: 82 x 82 x 40 mm
Shipping port: Xiamen
Warranty: 12 months
