Description

The BECKHOFF CP6202-0000-0070 is an industrial-grade Economy built-in Panel PC featuring an integrated 15-inch TFT display with a native resolution of 1024 x 768 pixels. Designed for installation in control cabinets, console desks, or control panels, this fanless Panel PC delivers spacesaving control and visualization technology directly at the machine. It is constructed with a durable aluminum front bezel and a protective sheet-steel rear housing cover, engineered to withstand demanding industrial production environments.

As a central control and visualization unit, the BECKHOFF CP6202-0000-0070 utilizes a high-performance 3.5-inch motherboard architecture. The system features built-in pull-out clamping levers that simplify the mechanical installation process, allowing secure and flush mounting into control panel cutouts without loose structural hardware. With its front-side IP65 protection rating, this Panel PC acts as a reliable operator interface for diverse industrial automation applications.

Features

• 15-inch active matrix TFT display with a clear 1024 x 768 resolution.
• Industrial aluminum front bezel paired with a sheet-steel rear housing.
• Integrated pull-out clamping levers for rapid, hardware-free installation in cutouts.
• Front panel protection rated to IP65, providing defense against dust and water.
• Integrated motherboard designed for continuous processing, control, and visualization.
• Versatile connectivity with multiple onboard USB 3.0, RS232, DVI, and Gigabit Ethernet interfaces.

Applications

• Human-Machine Interface (HMI) and operator control stations on factory floors.
• Industrial visualization, performance tracking, and process diagnostics.
• Control cabinet integration for automated manufacturing lines and machinery.
• Embedded computing and execution of PLC programs.

Technical Specifications

Installation Guidelines

1. Verify Unit and Requirements: Confirm that the BECKHOFF CP6202-0000-0070 is suitable for your environment and that the supply matches the nominal 24 V DC requirement.
2. De-energize the System: Ensure all electrical lines to the cabinet panel and the installation area are fully powered down before mounting the device.
3. Prepare Panel Cutout: Prepare the installation cutout in your cabinet or panel according to the standard dimensions specified for the 15-inch BECKHOFF Panel PC.
4. Insert and Secure: Push the Panel PC from the front into the cutout, then secure it firmly from the rear using the integrated pull-out clamping levers.
5. Connect Earth and Interfaces: Connect the functional ground wire, followed by necessary data interfaces, including Ethernet, USB, and DVI cables.
6. Apply Power and Boot: Connect the 24 V DC power supply line, power up the system, and confirm proper operating system initialization and display function.
