Beckhoff CP6732-0001-0060 CP67xx Economy Built-in Panel PC

SKU CP6732-0001-0060

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: CP6732-0001-0060
Origin Germany
Product Type: Panel PCs
Payment: T/T, Western Union
Weight: 5.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Designed to deliver robust industrial computing performance in a space-saving form factor, the Beckhoff CP6732-0001-0060 serves as an efficient built-in Panel PC optimized for demanding machine control, HMI visualization, and data acquisition tasks. This industrial-grade hardware platform integrates an efficient 3.5-inch motherboard with dual-core Intel Atom processing capabilities to execute real-time automation control using TwinCAT software.

The unit features a resilient mechanical design with an aluminum front bezel and a rugged sheet-steel rear cover. Installation is streamlined via pull-out clamping levers that ensure a secure, fast fit into control cabinets without loose parts. Dual onboard Gigabit Ethernet ports provide flexible physical network segregation, facilitating reliable communication between enterprise IT networks and deterministic field-level industrial networks.

Features

Rugged Enclosure: Features a high-quality aluminum front panel combined with a heavy-duty sheet-steel rear cover.
Efficient Processing: Equipped with an Intel Atom x5-E3930 dual-core processor operating at 1.3 GHz for dependable low-latency performance.
Industrial Ethernet: Two onboard 100/1000BASE-T RJ45 ports for high-speed network integration and network segregation.
Flexible Mounting: Uses an integrated pull-out clamping lever mechanism for fast and secure installation without loose mounting brackets.
Industrial Protection: IP65 protection rating on the front side when correctly panel-mounted, safeguarding internal electronics against dust and moisture ingress.

Applications

Automotive manufacturing and assembly lines
Packaging machine control systems
Water and wastewater processing facilities
Power generation and distribution monitoring
General human-machine interface (HMI) and SCADA applications

Technical Specifications

Parameter	Specification
Manufacturer	Beckhoff Automation
Part Number / Model	CP6732-0001-0060
Device Type	Economy Built-in Panel PC
Housing Material	Aluminum front with sheet-steel rear cover
Processor	Intel Atom x5-E3930, 1.3 GHz, 2 cores (TC3: 40)
Motherboard	3.5-inch motherboard for Intel Atom x5-E39xx
Memory	4 GB DDR4 RAM (up to 8 GB DDR4 RAM ex factory)
Storage Slots	1 slot for CFast (options for secondary CFast or 2.5-inch SSD)
Ethernet Interfaces	2 x 100/1000BASE-T onboard
USB Interfaces	2 x USB 3.0, 2 x USB 2.0
Video Output	1 x DVI-D
Power Supply	24 V DC (UPS options available)
Operating Temperature	0 to 55 degC
Front Protection Rating	IP65
Rear Protection Rating	IP20
Shipping Weight	5.0 kg

Connections and Interfaces

Interface Connection	Functionality / Protocol
Ethernet 1 (RJ45)	100/1000BASE-T Local Network / EtherCAT Control
Ethernet 2 (RJ45)	100/1000BASE-T Office / Upper-level Cloud Network
USB 3.0	High-speed peripheral connections (2 ports)
USB 2.0	Standard peripheral and input connections (2 ports)
DVI	External display output connection
Power Input	24 V DC power connection terminal

Installation Guidelines

Mounting Location: Install the Panel PC in a flat, rigid control cabinet cutout matching the specified mechanical layout.
Securing the Device: Pull out and lock the integrated clamping levers around the cutout perimeter to secure the front seal against the panel face.
Grounding: Ensure a low-impedance ground connection is made between the Panel PC chassis and the control cabinet earth ground bus.
Thermal Management: Maintain a minimum clearance of 50 mm above, below, and behind the device to allow proper passive convective cooling. Do not block rear ventilation slots.
Wiring: Route all communication cables (Ethernet, USB) separately from high-voltage AC power lines to prevent electromagnetic interference.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What processor is installed in the Beckhoff CP6732-0001-0060 Panel PC?

The CP6732-0001-0060 is equipped with an Intel Atom x5-E3930 dual-core processor operating at 1.3 GHz.

What is the ingress protection rating of this panel-mounted computer?

When properly installed in a control cabinet cutout, the front side is rated IP65 against dust and liquid ingress, while the rear housing is rated IP20.

How is the CP6732-0001-0060 Panel PC physically mounted?

It uses pull-out clamping levers integrated on the sides of the housing for fast, secure installation into cabinet cutouts without loose brackets.

What is the operating temperature range for the Beckhoff CP6732-0001-0060?

This industrial Panel PC is rated for an ambient operating temperature range of 0 to 55 degC.

How many network ports does this built-in PC provide?

It features two onboard 100/1000BASE-T Gigabit Ethernet interfaces for connection to physical control networks and IT environments.
