The BECKHOFF CP6929-0001-0000 is a compact built-in Control Panel configured with a 6.5-inch display featuring a resolution of 640 x 480 pixels. It is designed to function as an operator interface terminal, mounting directly into control cabinet doors, consoles, or mounting arms. Built with an aluminum front bezel and a sheet-steel rear cover, this panel provides a reliable, rugged interface for severe industrial operating environments.
Equipped with integrated DVI-E and USB-E 2.0 interface technology, the CP6929-0001-0000 enables digital video and high-speed USB data transmission over distances of up to 50 meters from the control industrial PC. This architecture allows the host computer to be situated in a secure, climate-controlled location while giving local operators access on the factory floor. Standard connections include a DVI input, RJ45 for USB-E 2.0, and local USB 2.0 ports.
| Manufacturer | BECKHOFF |
| Model | CP6929-0001-0000 |
| Device Type | Built-in Control Panel |
| Display Size | 6.5-inch |
| Resolution | 640 x 480 pixels |
| Front Panel Material | Aluminum bezel |
| Rear Cover Material | Sheet steel |
| Supply Voltage | 24 V DC |
| Remote Connection Technology | DVI-E and USB-E 2.0 (up to 50 m) |
| Standard Interfaces | DVI input, RJ45 (USB-E 2.0), 2 x USB 2.0 |
| Local USB Interface Limit | Up to 5 m using standard USB 2.0 input |
| Front Protection Rating | IP65 (when properly installed) |
| Rear Protection Rating | IP20 |
| Operating Temperature | 0 to 55 degC |
| Mounting Mechanism | Pull-out clamping levers |
| Interface or Terminal | Function |
|---|---|
| DVI Input | Receives video signal from industrial PC |
| RJ45 (USB-E 2.0) | Receives remote USB communication signal up to 50 m |
| 2 x USB 2.0 Ports | Local ports for peripheral hardware connection |
| 24 V DC Terminal | Power supply connection input |
