BECKHOFF CP7722-0001-0050 CP77xx Panel PC

SKU CP7722-0001-0050

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: CP7722-0001-0050
  • Origin Germany
  • Product Type: Panel PCs
  • Payment: T/T, Western Union
  • Weight: 8.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CP77xx HMI Panel PCs
Quantità
Call sales Contact

Product Description

Description

Designed for mounting arm installation, the CP7722-0001-0050 industrial panel PC integrates a high-resolution 15-inch control display directly with high-performance control architecture inside a compact, IP65-rated aluminum housing. This unit acts as a robust human-machine interface (HMI) and controller, built to withstand harsh manufacturing environments. It features a completely sealed housing that prevents dust and moisture ingress, making it highly reliable for direct on-machine deployment.

The processing power is driven by an Intel Atom processor, optimized for thermal efficiency and real-time execution of TwinCAT control software. Equipped with high-speed Gigabit Ethernet ports and industrial-grade serial interfaces, the BECKHOFF CP7722-0001-0050 ensures rapid fieldbus and network integration, serving as an effective centralized control hub for modern factory floor machinery.

Features

  • Rugged aluminum housing with all-around IP65 protection rating, eliminating the need for separate control cabinets.
  • High-quality 15-inch TFT display with a resolution of 1024 x 768 pixels for clear visualization of complex process screens.
  • Industrial-grade motherboard architecture tailored for Intel Atom processors, ensuring fanless, low-power operation.
  • Flexible connectivity including dual Gigabit Ethernet ports and a configurable RS232 serial interface via specialized sealed connectors.
  • Mechanically stable backplane installation with integrated mounting arm adapter interface.

Applications

  • Automotive assembly lines and robot control stations.
  • Food processing and packaging machinery requiring high IP ratings.
  • Metalworking and CNC machining visualization terminals.
  • Water and wastewater plant control systems.

Technical Specifications

ManufacturerPart Number / ModelDisplay SizeResolutionHousing MaterialProtection ClassProcessorSystem MemoryStorageInterfacesOperating TemperaturePower Supply InputMounting MethodShipping Weight
BECKHOFF
CP7722-0001-0050
15-inch
1024 x 768 pixels
Sealed aluminum housing
IP65 (all sides)
Intel Atom x5-E39xx series
4 GB DDR4 RAM
40 GB CFast flash memory
2 x 10/100/1000BASE-T RJ45 (IP65 connector), 1 x RS232 serial interface (DIN 12-pin to D-sub 9-pin adapter)
0 to 45 degC
24 V DC
4 x M6 x 18 mm threaded holes in the backplane; mounting arm adapter
8.0 kg

Connections and Interfaces

Connector Type Function
2 x RJ45 (IP65 sealed) Dual Gigabit Ethernet (10/100/1000 Mbps) network interfaces
DIN 12-pin (IP65 sealed) RS232 serial communication (uses included adapter to 9-pin D-sub)
Power Supply Terminal 24 V DC system power input

Installation Guidelines

  • Mounting: Secure the unit using the 4 integrated M6 x 18 mm threaded holes located on the backplane, or attach via the designated mounting arm adapter. Ensure the mounting structure can support the weight of the unit safely.
  • Environmental: Maintain clear air circulation around the outer aluminum cooling fins. The ambient temperature during operation must remain between 0 and 45 degC.
  • Cabling: Only use IP65-rated industrial mating connectors and adapter cables to maintain the overall sealing integrity of the panel. Ensure correct shielding of communication lines to prevent electromagnetic interference.
  • Grounding: Ensure the housing is properly grounded to the machine frame or grounding bar via a low-resistance path.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the ingress protection (IP) rating of the CP7722-0001-0050?
The panel PC features a fully sealed aluminum housing that provides IP65 protection from all sides, making it resistant to dust and water jets.
How is the CP7722-0001-0050 mounted to control systems?
It is designed for mounting arm installation using four M6 x 18 mm threaded holes in the backplane or an integrated mounting arm adapter.
What are the serial communication options for this model?
The unit features a DIN 12-pin IP65 connector on the backplane for RS232 communication, which interface with standard systems via a DIN-to-D-sub 9-pin adapter cable.
