Beckhoff EL1262-0050 2-Channel Digital Input Terminal (5 V DC, Oversampling)

SKU EL1262-0050

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: EL1262-0050
Origin Germany
Product Type: EtherCAT Terminal
Payment: T/T, Western Union
Weight: 2.0 kg
Dimensions: 12 mm x 100 mm x 68 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The EL1262-0050 is a specialized EtherCAT Terminal from Beckhoff designed for high-speed signal acquisition. Featuring 2 channels with a nominal voltage of 5 V DC, this terminal excels in applications requiring precise timing, such as high-resolution event logging. Its key advantage is its oversampling capability, allowing it to sample input signals at up to 1 Msample/s (n = 1...1000 factor), providing an extremely fine-grained view of signal states that exceeds standard cycle times.

Features

Oversampling Capability: Enables signal sampling at rates higher than the bus cycle time (max. 1 Msample/s).
High-Precision Timing: Features Distributed Clocks (DC) support with precision << 1 µs, making it ideal for synchronized timestamping.
Compact Design: Integrates advanced processing into a standard 12 mm wide housing.
Flexible Input Logic: Supports 5 V DC logic signals, common in TTL-based sensors or high-speed encoder feedback interfaces.
Galvanic Isolation: Ensures 500 V isolation between the E-bus and field potential, protecting the controller from signal-side surges.

Technical Specifications

Feature	Specification
Manufacturer	Beckhoff
Model	EL1262-0050
Number of Inputs	2
Nominal Voltage	5 V DC
Sampling Rate	max. 1 Msample/s
Input Filter	< 1 µs
Oversampling Factor	n = 1…1000
Clock Precision	<< 1 µs (Distributed Clocks)
Dimensions (WxHxD)	12 mm x 100 mm x 68 mm
Weight	~55 g

Installation and Integration Notes

Wiring: Utilizes 4-wire connection technology. Connections support solid (0.08–2.5 mm²) and flexible (0.14–1.5 mm²) conductors.
Sync Configuration: Because this terminal uses Distributed Clocks, ensure that the EtherCAT Master (e.g., TwinCAT) is configured to synchronize the terminal's internal clock to the master clock to achieve the specified < 1 µs precision.
Process Image: The process image includes both the input data and a 64-bit CycleCounter/latch, which is essential for tracking when specific samples occurred relative to the bus cycle.
Environment: Designed for operation between 0 °C and +55 °C. Ensure proper airflow in the control cabinet when using multiple high-density terminals.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary advantage of the oversampling feature on this terminal?

Oversampling allows the terminal to sample input signals at a rate higher than the EtherCAT bus cycle, capturing transient signal states that would otherwise be missed.

Does the EL1262-0050 support Distributed Clocks?

Yes, it supports Distributed Clocks with a precision of << 1 µs, allowing for accurate timestamping of events.

What signal voltage level is required for this terminal?

The terminal is designed for a nominal voltage of 5 V DC.

How is the oversampling factor defined?

The oversampling factor (n) is an integer multiple of the cycle time, configurable between 1 and 1000.
