BECKHOFF KL1889 Bus Terminal Series HD Bus Terminal

SKU KL1889

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: KL1889
  • Origin Germany
  • Product Type: HD Bus Terminals
  • Payment: T/T, Western Union
  • Weight: 0.055 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Bus Terminals HD Bus Terminals
Quantità
Call sales Contact

Product Description

Description

Engineered for high-density space conservation in control cabinets, the BECKHOFF KL1889 is a High-Density (HD) Bus Terminal featuring sixteen digital inputs in a compact 12 mm housing width. Operating with negative switching (sink) logic, this module incorporates 1-wire connection technology, allowing direct connection of sensors and signals to the process image without excessive terminal blocks. Designed for seamless integration into K-bus networks, the KL1889 enables efficient signal acquisition in restricted spaces while simplifying wiring and minimizing hardware requirements.

Features

  • Provides 16 digital inputs within a compact 12 mm mechanical footprint.
  • Utilizes negative switching (sink) logic configuration.
  • Employs 1-wire connection technology with direct plug-in connection for solid conductors.
  • Tool-free termination for solid conductors; simple spring actuation by screwdriver for stranded wires and ferrules.
  • Integrated hardware input filter (typ. 3.0 ms) to suppress line bounce and noise.
  • Complete 500 V galvanic isolation between the internal K-bus and the field potential.
  • Address-free configuration for immediate plug-and-play installation within the Bus Coupler process image.

Applications

  • Space-constrained decentralized control systems and distribution cabinets.
  • Automated assembly systems, packaging machinery, and material handling lines.
  • Sensor signal concentration in industrial process automation.
  • General manufacturing and PLC I/O expansion environments.

Technical Specifications

Manufacturer BECKHOFF
Part Number/Model KL1889
Connection Technology 1-wire
Specification Negative switching (sink)
Number of Inputs 16
Nominal Voltage 24 V DC (-15% / +20%)
"0" Signal Voltage 18 to 30 V
"1" Signal Voltage 0 to 7 V
Input Filter typ. 3.0 ms
Input Current typ. 3 mA
Current Consumption (K-bus) typ. 20 mA
Current Consumption (Power Contacts) typ. 4 mA + load
Electrical Isolation 500 V (K-bus to field potential)
Bit Width in Process Image 16 inputs
Conductor Connection (Solid) Direct plug-in technique (0.08 to 1.5 mm²)
Conductor Connection (Stranded) Spring actuation by screwdriver (0.25 to 1.5 mm²)
Conductor Connection (Ferrule) Spring actuation by screwdriver (0.14 to 0.75 mm²)
Weight approx. 55 g
Operating Temperature 0 to +55 degC
Storage Temperature -25 to +85 degC
Relative Humidity 95%, non-condensing
Vibration / Shock Resistance Conforms to EN 60068-2-6 / EN 60068-2-27
EMC Immunity / Emission Conforms to EN 61000-6-2 / EN 61000-6-4
Protection Class IP20

Connections and Interfaces

Connection Type Conductor Type Cross-section Range
Direct Plug-In Solid Wire 0.08 to 1.5 mm²
Screwdriver Spring Actuation Stranded Wire 0.25 to 1.5 mm²
Screwdriver Spring Actuation Ferrule 0.14 to 0.75 mm²

Installation Guidelines

  • Ensure the system power supply is completely disconnected before mounting or removing the terminal.
  • Mount the module onto a standard 35 mm DIN rail (EN 60715) with vertical or horizontal mounting orientation as required.
  • Ensure the side locking mechanism of the bus terminal engages correctly with adjacent terminals to secure reliable K-bus and power contact transmission.
  • Utilize appropriate shielding and grounding procedures for sensor lines to prevent electromagnetic interference from distorting input signals.

Compliance and Certifications

  • CE
  • UL
