General Electric

GE Energy IS230PCAAH1B Mark VIe Core Analog Module

SKU IS230PCAAH1B

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: General Electric
  • Product No.: IS230PCAAH1B
  • Origin United States
  • Product Type: Core Analog Module
  • Payment: T/T, Western Union
  • Weight: 1.2 kg
  • Dimensions: 28.0 x 18.0 x 8.0 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Core Analog Module Mark VIe
Quantità
Call sales Contact

Product Description

Description

The IS230PCAAH1B is a Core Analog I/O Module manufactured by GE Energy for the Mark VIe gas turbine control system. It processes the primary portion of analog input and output signals required for gas turbine operation. Internal hardware incorporates a BPPC processor board paired with two application I/O boards (BCAA and BCAB) and a TCAS terminal board. The hardware design accepts analog input/output signals, LVDT excitation outputs, and TTL pulse inputs with power. Signals intended for a single hardware module connect directly to the edge terminal blocks, while signals fanned to simplex or TMR configurations route through an optional TCAT terminal board.

Features

  • Integrated BPPC processor board, BCAA and BCAB application I/O boards, and TCAS terminal board
  • Edge-mounted 120 Euro-style box-type terminal blocks for field device wiring
  • Support for fanned seismic inputs, fanned 4-20 mA inputs, and fanned LVDT feedback via an optional TCAT terminal board
  • Interface connections including dual RJ-45 Ethernet ports and a 28 V dc power connector
  • Three front-facing LED status indicators

Applications

  • Gas turbine core analog signal processing
  • Speed and position feedback acquisition in Mark VIe control systems
  • Industrial turbine control I/O interfacing

Technical Specifications

Parameter Specification
Manufacturer GE Energy
Part Number IS230PCAAH1B
Product Type Core Analog Module
Series Mark VIe
Primary Functional Revision B-rated
Chassis Type Vented Chassis Style
Thermocouple Types E, J, K, T, S
Analog Function Core Analog
Accepted Signals Analog input and output signals, LVDT excitation outputs, TTL pulse inputs + power
Power Connector 28 V dc power connector
Network Interfaces Dual RJ-45 Ethernet connectors
Field Terminal Blocks 120 Euro-style box-type terminal blocks
Visual Indicators 3 front-facing LEDs

Installation Guidelines

  • Ensure 28 V dc power is safely disconnected prior to mounting or wiring the unit.
  • Connect field wiring to the 120 Euro-style box-type terminal blocks located on the module edge.
  • Direct single-module signals directly to the local terminals; route fanned signals for simplex or TMR setups through the optional TCAT terminal board.
  • Connect network communication cables to the dual RJ-45 Ethernet ports.
  • Maintain adequate spacing around the vented chassis to ensure passive thermal cooling.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What internal boards are included in the module assembly?
The device contains a BPPC processor board, two application I/O boards (BCAA and BCAB), and a TCAS terminal board.
Which thermocouple types does the module support?
The device supports thermocouple types E, J, K, T, and S.
What is the function of the optional TCAT board?
The optional TCAT board enables fanned signal routing for seismic inputs, analog 4-20 mA inputs, and LVDT feedback in simplex or TMR configurations.
What power connection does the module require?
The module requires a 28 V dc power connection.
