Mitsubishi Electric GM-SHYF-RH SHY Series Right Angle Hollow Shaft Geared Motor

SKU GM-SHYF-RH

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Mitsubishi Electric
Product No.: GM-SHYF-RH
Origin United States
Product Type: Geared Motors
Payment: T/T, Western Union
Weight: 20.0 kg
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

Engineered for high-torque efficiency in space-constrained industrial systems, the Mitsubishi Electric GM-SHYF-RH is a premium right-angle geared motor belonging to the highly reliable SHY Series. This unit combines a space-saving hollow shaft configuration with a versatile housing design that supports both flange-type and face-mounting installations. By utilizing advanced hypoid gear technology, this geared motor delivers superior mechanical efficiency and reduced noise levels compared to traditional worm gear units, making it an ideal choice for continuous-duty industrial automation applications.

Features

Right-Angle Hypoid Gear Design: Delivers high transmission efficiency with quiet, low-vibration operation.
Hollow Shaft (H) Configuration: Eliminates the need for flexible couplings, reducing overall machine footprint and mechanical complexity.
Dual Mounting Flexibility (F): Integrated housing supports both flange and face mounting for versatile installation options.
Robust Construction: Engineered to withstand high radial and axial loads in harsh industrial environments.
Optimized Heat Dissipation: High-grade aluminum or cast iron casing designed for efficient thermal management.

Applications

Conveyor and material handling systems
Packaging machinery and automated lines
Food processing and bottling equipment
Intralogistics and sorting machinery

Technical Specifications

Parameter	Specification
Manufacturer	Mitsubishi Electric
Model / Part Number	GM-SHYF-RH
Product Series	SHY Series (Super Helical/Hypoid)
Motor Type Designation	GM (Geared Motor)
Gear Type	Right Angle (R)
Output Shaft Type	Hollow Shaft (H)
Mounting Configuration	Flange Type and Face Mounting (F)
Approximate Weight	20.0 kg
Operating Temperature Range	-15 to +40 degC (non-freezing)

Installation Guidelines

Alignment: Ensure the driven shaft is precisely aligned with the hollow shaft of the GM-SHYF-RH to prevent premature bearing wear and mechanical fatigue.
Mounting: Securely anchor the unit using high-tensile bolts through either the flange or face-mounting interfaces. Refer to the manufacturer's mechanical drawing for torque specifications.
Ventilation: Provide adequate clearance around the motor housing to facilitate natural convection and prevent thermal overloading.
Electrical Grounding: Always connect the motor frame grounding terminal to the plant earth system in accordance with local electrical codes.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What does the "RH" designation mean on the GM-SHYF-RH geared motor?

The "R" indicates a right-angle gear arrangement (utilizing hypoid gears for high efficiency), and the "H" indicates a hollow shaft output design.

What are the mounting options available for the GM-SHYF-RH?

The "F" designation signifies dual-mounting compatibility, meaning the unit can be mounted using either its flange face or its front face-mount threads.

What is the operating temperature range for this geared motor?

The standard operating temperature range for the Mitsubishi Electric SHY series geared motors is -15 to +40 degC, ensuring it remains in a non-freezing environment.
