GT2505-VTBD

Mitsubishi Electric

Mitsubishi Electric GT2505-VTBD GT25 Series HMI

SKU GT2505-VTBD

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: GT2505-VTBD
  • Origin United States
  • Product Type: Human Machine Interfaces
  • Payment: T/T, Western Union
  • Weight: 0.6 kg
  • Dimensions: 16.4 cm x 13.9 cm x 5.35 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

GT25 Series HMI Human Machine Interfaces
Quantità
Call sales Contact

Product Description

Description

Designed for space-conscious industrial automation applications, the GT2505-VTBD belongs to the high-performance Mitsubishi Electric GT25 Series of human-machine interfaces. This mid-range graphic operation terminal integrates robust display capabilities with an analog resistive touchscreen system, providing operators with a reliable portal for real-time PLC monitoring and parameter entry. Engineered to serve as a cost-efficient yet powerful visual control interface, the module fits seamlessly into standardized panel cutouts and connects to dominant plant networks.

The unit features a bright 5.7-inch TFT color display that outputs crisp, high-visibility diagnostics under diverse industrial lighting conditions. Operating on a low-voltage DC auxiliary power input, this black-bezeled interface minimizes space consumption inside control cabinets while maximizing display resolution and response metrics.

Features

  • High-density 5.7-inch TFT color LCD screen.
  • Clear VGA resolution displaying up to 640 x 480 dots for precise graphical readouts.
  • Analog resistive film touch panel supporting flexible software button configurations.
  • Industrial black bezel housing optimized for panel-mount setups.
  • Low-profile form factor with an installation depth of only 5.35 cm.
  • Highly reliable solid-state architecture designed for high-vibration environments.

Applications

  • Automotive assembly lines and conveyor control systems.
  • Packaging, labeling, and continuous bottling machines.
  • Water treatment facility diagnostic panels.
  • Pumping stations and local auxiliary power plant monitoring.

Technical Specifications

Parameter Value
Manufacturer Mitsubishi Electric
Part Number/Model GT2505-VTBD
Series GT25 Series HMI (GOT2000)
Display Type TFT color LCD
Screen Size 5.7 inches
Resolution 640 x 480 VGA
Effective Display Size (W x H) 115.2 mm x 86.4 mm
Touch Panel Type Analog resistive film
Bezel/Panel Color Black
Power Supply 24V DC
External Dimensions (W x H x D) 16.4 cm x 13.9 cm x 5.35 cm
Panel Cutout Dimensions (W x H) 15.3 cm x 12.1 cm
Weight 0.6 kg (excluding mounting brackets)

Installation Guidelines

  • Prepare the cabinet enclosure panel with a precise cutout matching the 15.3 cm by 12.1 cm template specifications.
  • Mount the unit using the designated brackets to maintain environmental ingress integrity on the front face.
  • Route low-voltage 24V DC power cabling separately from high-voltage AC lines to minimize electrical noise interference.
  • Ensure the internal cabinet operating temperature remains within standard ambient specifications by providing adequate ventilation clearance.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the display size and resolution of the GT2505-VTBD?
The GT2505-VTBD features a 5.7-inch TFT color display with a VGA resolution of 640 x 480 pixels.
What input voltage is required to power this HMI unit?
This module operates on a standard 24V DC power supply.
What are the physical dimensions required for the panel cutout during installation?
The required panel cutout dimensions for installation are 15.3 cm in width by 12.1 cm in height.
What type of touchscreen technology is utilized in the GT2505-VTBD?
The interface uses an analog resistive film touch panel.
Reviews

More from this brand

Mitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Q06UDHCPUMitsubishi Electric Q06UDEHCPU MELSEC-Q Series Universal PLC CPU Module
Mitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
FX3U-128MR/ES-AMitsubishi Electric FX3U-128MR/ES-A | FX3U Series Main Unit
Mitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
MR-J3-40AMitsubishi MELSEC MR-J3-40A Servo Amplifier | 400W 3-Phase or 1-Phase 200V
Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier
MR-J2S-40A-S004Mitsubishi MR-J2S-40A-S004 | 400W AC Servo Amplifier

GT2505-VTBD

Stock & lead time on request

Call
  • GT2505-VTBD
1 1

Mitsubishi Electric GT2505-VTBD GT25 Series HMI

Only 10 item(s) left in stock

  • Manufacturer: Mitsubishi Electric

  • Product No.: GT2505-VTBD

  • Country of origin:United States

  • Product Type: Human Machine Interfaces

  • Payment: T/T, Western Union

  • Weight: 600g

  • Dimensions: 16.4 cm x 13.9 cm x 5.35 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Designed for space-conscious industrial automation applications, the GT2505-VTBD belongs to the high-performance Mitsubishi Electric GT25 Series of human-machine interfaces. This mid-range graphic operation terminal integrates robust display capabilities with an analog resistive touchscreen system, providing operators with a reliable portal for real-time PLC monitoring and parameter entry. Engineered to serve as a cost-efficient yet powerful visual control interface, the module fits seamlessly into standardized panel cutouts and connects to dominant plant networks.

The unit features a bright 5.7-inch TFT color display that outputs crisp, high-visibility diagnostics under diverse industrial lighting conditions. Operating on a low-voltage DC auxiliary power input, this black-bezeled interface minimizes space consumption inside control cabinets while maximizing display resolution and response metrics.

Features

  • High-density 5.7-inch TFT color LCD screen.
  • Clear VGA resolution displaying up to 640 x 480 dots for precise graphical readouts.
  • Analog resistive film touch panel supporting flexible software button configurations.
  • Industrial black bezel housing optimized for panel-mount setups.
  • Low-profile form factor with an installation depth of only 5.35 cm.
  • Highly reliable solid-state architecture designed for high-vibration environments.

Applications

  • Automotive assembly lines and conveyor control systems.
  • Packaging, labeling, and continuous bottling machines.
  • Water treatment facility diagnostic panels.
  • Pumping stations and local auxiliary power plant monitoring.

Technical Specifications

Parameter Value
Manufacturer Mitsubishi Electric
Part Number/Model GT2505-VTBD
Series GT25 Series HMI (GOT2000)
Display Type TFT color LCD
Screen Size 5.7 inches
Resolution 640 x 480 VGA
Effective Display Size (W x H) 115.2 mm x 86.4 mm
Touch Panel Type Analog resistive film
Bezel/Panel Color Black
Power Supply 24V DC
External Dimensions (W x H x D) 16.4 cm x 13.9 cm x 5.35 cm
Panel Cutout Dimensions (W x H) 15.3 cm x 12.1 cm
Weight 0.6 kg (excluding mounting brackets)

Installation Guidelines

  • Prepare the cabinet enclosure panel with a precise cutout matching the 15.3 cm by 12.1 cm template specifications.
  • Mount the unit using the designated brackets to maintain environmental ingress integrity on the front face.
  • Route low-voltage 24V DC power cabling separately from high-voltage AC lines to minimize electrical noise interference.
  • Ensure the internal cabinet operating temperature remains within standard ambient specifications by providing adequate ventilation clearance.

RECOMMENDED RELATED MODELS

Product Image Model Number / Title Condition Availability Action
2711P-T6C20D8 Allen-Bradley 2711P-T6C20D8 PanelView Plus 6 600 Human Machine Interface Original New In Stock View Details
Key Features:
#GT25 Series #HMI #Human Machine Interfaces
