Description

Designed for high-performance motion control applications, the Mitsubishi Electric HG-SR102J is a medium-inertia rotary AC servo motor engineered within the industrial HG-SR Series lineup. This motor delivers precise torque and speed execution when paired with compatible MELSERVO-J4 servo amplifiers, making it ideal for machinery demanding rigorous speed regulation and reliable torque response. Equipped with an integrated oil seal (signified by the "J" suffix), the unit is constructed to withstand industrial environments by preventing fluid ingress along the drive shaft.

Features

• Medium-inertia design optimized for stable load matching and smooth mechanical transition.
• Integrated factory-installed oil seal for robust shaft protection.
• High-temperature protection compliant with Insulation Class 155 (F) specifications.
• Vibration rank V10 rating ensures exceptional mechanical balance and reduced structural stress.
• Brushless AC design minimizes maintenance requirements and extends operating life.

Applications

• Material handling systems and conveyors
• Packaging and labeling machinery
• Textile processing equipment
• Automated food and beverage production lines
• General industrial positioning axes

Technical Specifications

Installation Guidelines

• Shaft Alignment: Ensure precise alignment with the driven shaft using flexible couplings to minimize radial and axial load limits.
• Environmental Protection: Mount the motor in an indoor location shielded from direct sunlight. Ensure the environment is free from flammable gases, corrosive agents, oil mist, and excessive dust.
• Thermal Management: Maintain unobstructed airflow around the motor frame to ensure adequate heat dissipation during continuous high-load operations.
• Electrical Grounding: Securely bond the motor's protective earth (PE) terminal to the system ground bus before applying power.
