MR-J2S-15KA

Mitsubishi Electric

Mitsubishi Electric MR-J2S-15KA MELSERVO-J2-Super General-Purpose AC Servo Amplifier

SKU MR-J2S-15KA

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric
  • Product No.: MR-J2S-15KA
  • Origin United States
  • Product Type: Servo Amplifiers
  • Payment: T/T, Western Union
  • Weight: 35.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

MELSERVO-J2-Super Servo Amplifiers
Quantità
Call sales Contact

Product Description

Description

Designed to handle high-capacity precise motion control, the Mitsubishi Electric MR-J2S-15KA is a high-performance AC servo amplifier belonging to the widely-adopted MELSERVO-J2-Super series. This drive provides a rated output of 15 kW, offering highly responsive speed, torque, and position control for heavy-duty industrial automation applications. Equipped with a general-purpose interface, it accepts analog voltage commands and pulse train inputs, ensuring straightforward integration with external PLCs and CNC motion controllers. The unit incorporates dynamic brake functions, self-diagnostic capabilities, and robust protection circuitry to maintain operational safety and reliability in demanding automation environments.

Features

  • High power output capacity of 15 kW for demanding industrial loads.
  • General-purpose interface supporting both analog voltage control and pulse train input.
  • Real-time auto-tuning function for automatic matching of load inertia.
  • Advanced vibration suppression control algorithms to minimize machine mechanical resonance.
  • Built-in dynamic brake for fast, reliable emergency deceleration.
  • Absolute position detection capability when integrated with compatible absolute encoder servo motors.

Applications

  • Metal stamping, pressing, and heavy forming machinery
  • High-capacity packaging and material handling systems
  • Large-scale CNC machine tools and gantry axes
  • Heavy-duty automated warehousing and retrieval systems
  • Paper conversion and textile manufacturing systems

Technical Specifications

Manufacturer Mitsubishi Electric
Model/Part Number MR-J2S-15KA
Series MELSERVO-J2-Super (MELSERVO-J2S)
Rated Output Capacity 15 kW
Power Supply 3-phase 200 to 230 VAC, 50/60 Hz
Control System Sine-wave PWM control, current control system
Interface Type General-Purpose (Analog / Pulse Train)
Recommended Breaker Frame 225A Frame (125A rated no-fuse breaker)
Recommended Contactor S-N95
Cooling Method Forced cooling fan
Ambient Operating Temperature 0 to 55 degC (non-freezing)
Ambient Operating Humidity 90% RH maximum (non-condensing)
Weight 35 kg

Connections and Interfaces

Connector Identifier Primary Function
CN1A Control signal interface (I/O commands, pulse train)
CN1B Extended control input/output connections
CN2 Encoder feedback connection (serial communication link)
CN3 RS-232C communication interface for PC setup software

Installation Guidelines

  • Mount the servo amplifier vertically on a flat, clean surface to allow proper thermal convection.
  • Maintain a minimum clearance of at least 10 mm on both lateral sides and 80 mm above and below the amplifier for adequate fan-driven airflow.
  • Utilize shielded twisted-pair cables for control signal inputs to prevent electro-magnetic interference (EMI).
  • Ensure solid grounding by connecting the ground terminal to a Class 3 or better dedicated grounding point.

Compliance and Certifications

  • CE Mark
  • UL Listed
  • cUL
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What interface does the MR-J2S-15KA use?
The MR-J2S-15KA features a general-purpose ('A' type) interface that accepts analog voltage commands and pulse train inputs.
What is the rated power output of this servo amplifier?
This model has a rated power output capacity of 15 kW.
What recommended peripheral hardware is required for circuit protection?
For correct installation and safety, a 225A frame (125A rated) no-fuse breaker and an S-N95 magnetic contactor are recommended.
