General Electric UR8LH Picture
General Electric UR8LH Picture
General Electric UR8LH Picture
1 / 3

General Electric

UR8LH GE Multilin UR-8LH Universal Relay CT/VT Module

SKU UR-8LH

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: General Electric
  • Product No.: UR-8LH
  • Origin United States
  • Product Type: Multilin Ct/vt Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 1.16 kg
  • Dimensions: 6cm x 19.5cm x 17.2cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

CT/VT Module
Quantità
Call sales Contact

Product Description

Description

The UR-8LH (UR8LH) is a high-performance current transformer and voltage transformer (CT/VT) interface module developed for the General Electric Universal Relay (UR) series. This module functions as the primary analog input interface, scaling down high-voltage and high-current grid values into precise, low-level signals that the internal relay processing unit can safely analyze. It features an integrated architecture providing 4CT and 4VT channels along with enhanced diagnostic capabilities. The UR-8LH continuously verifies analog signal integrity through an embedded hardware algorithm, enabling immediate detection of signal anomalies to ensure substation protection system reliability. System operators can monitor live metering values, ratios, and diagnostic data locally via the relay front faceplate liquid-crystal display or remotely through the EnerVista UR software suite.

Features

  • Provides a combined 4CT and 4VT channel configuration within a single slot module.
  • Features enhanced diagnostic algorithms for real-time validation of analog signal integrity.
  • Supports standard 3-phase current monitoring plus dedicated ground current detection.
  • Delivers seamless integration with the GE Multilin Universal Relay architecture.
  • Enables high-precision scaling of hazardous system current and voltage levels for safe relay calculation.

Applications

  • Utility and industrial substation protection and control systems.
  • Three-phase feeder, transmission line, and transformer monitoring.
  • High-reliability power system automated diagnostic architectures.
  • Retrofitting and upgrading existing GE Universal Relay hardware configurations.

Technical Specifications

Parameter Specification
Model Number UR-8LH (UR8LH)
Product Type CT/VT Module
Manufacturer GE Multilin and GE Grid Solutions
Part Number UR 8LH
Phase CTs 3 channels, 1A/5A
Ground CTs 1 channel, 1A/5A
VTs 4 channels
Country of Origin USA
Weight 2lb, 9oz

Installation Guidelines

  • Module Insertion: Ensure the Universal Relay chassis is completely powered down before inserting or replacing the module to prevent damage to internal backplane connectors.
  • CT Secondary Circuiting: Never open-circuit a current transformer secondary circuit while the primary side is energized. Ensure all CT blocks are shorted securely prior to removing wiring or the module.
  • Wiring Integrity: Route analog input signals through shielded twisted-pair cables to mitigate the effects of electromagnetic interference (EMI) and radio frequency interference (RFI) common in high-voltage substations.
  • Software Configuration: Following physical installation, connect via EnerVista UR software to map the new hardware matrix and verify that the ratio settings match the primary instrument transformers.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the enhanced diagnostics on this module?
The enhanced diagnostics utilize an internal algorithm to continuously verify the integrity of incoming analog signals, ensuring the reliability of the scaled voltage and current readings before processing.
Can the phase and ground CT inputs be configured for both 1A and 5A secondary ratings?
Yes, the module is engineered to accommodate standard 1A or 5A secondary current transformer inputs for both the three phase CT channels and the single ground CT channel.
How can an engineer access the diagnostic data generated by the module?
Diagnostic values and scaled analog measurements can be viewed directly through the liquid-crystal display on the front faceplate of the relay or remotely via the EnerVista UR software.
Reviews

More from this brand

GE Fanuc IC693MDL655H Series 90-30 32-Point DC Positive/Negative Logic Input Module
IC693MDL655HGE Fanuc IC693MDL655H Series 90-30 32-Point DC Positive/Negative Logic Input Module
GE Fanuc IC693CMM311 Series 90-30 Communications Co-Processor Module
IC693CMM311GE Fanuc IC693CMM311 Series 90-30 Communications Co-Processor Module
General Electric IS200VSVOH1BDC Mark VI Servo Control Card
IS200VSVOH1BDCGeneral Electric IS200VSVOH1BDC Mark VI Servo Control Card
GE Multilin 750-P5-G1-S1-HI-A20-R Feeder Management Relay
750-P5-G1-S1-HI-A20-RGE Multilin 750-P5-G1-S1-HI-A20-R Feeder Management Relay

UR-8LH

Stock & lead time on request

Call
  • General Electric UR8LH Picture
  • General Electric UR8LH Picture
  • General Electric UR8LH Picture
1 3

UR8LH GE Multilin UR-8LH Universal Relay CT/VT Module

Only 7 item(s) left in stock

  • Manufacturer: General Electric

  • Product No.: UR-8LH

  • Country of origin:United States

  • Product Type: Multilin Ct/vt Module

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 1160g

  • Dimensions: 6cm x 19.5cm x 17.2cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

The UR-8LH (UR8LH) is a high-performance current transformer and voltage transformer (CT/VT) interface module developed for the General Electric Universal Relay (UR) series. This module functions as the primary analog input interface, scaling down high-voltage and high-current grid values into precise, low-level signals that the internal relay processing unit can safely analyze. It features an integrated architecture providing 4CT and 4VT channels along with enhanced diagnostic capabilities. The UR-8LH continuously verifies analog signal integrity through an embedded hardware algorithm, enabling immediate detection of signal anomalies to ensure substation protection system reliability. System operators can monitor live metering values, ratios, and diagnostic data locally via the relay front faceplate liquid-crystal display or remotely through the EnerVista UR software suite.

Features

  • Provides a combined 4CT and 4VT channel configuration within a single slot module.
  • Features enhanced diagnostic algorithms for real-time validation of analog signal integrity.
  • Supports standard 3-phase current monitoring plus dedicated ground current detection.
  • Delivers seamless integration with the GE Multilin Universal Relay architecture.
  • Enables high-precision scaling of hazardous system current and voltage levels for safe relay calculation.

Applications

  • Utility and industrial substation protection and control systems.
  • Three-phase feeder, transmission line, and transformer monitoring.
  • High-reliability power system automated diagnostic architectures.
  • Retrofitting and upgrading existing GE Universal Relay hardware configurations.

Technical Specifications

Parameter Specification
Model Number UR-8LH (UR8LH)
Product Type CT/VT Module
Manufacturer GE Multilin and GE Grid Solutions
Part Number UR 8LH
Phase CTs 3 channels, 1A/5A
Ground CTs 1 channel, 1A/5A
VTs 4 channels
Country of Origin USA
Weight 2lb, 9oz

Installation Guidelines

  • Module Insertion: Ensure the Universal Relay chassis is completely powered down before inserting or replacing the module to prevent damage to internal backplane connectors.
  • CT Secondary Circuiting: Never open-circuit a current transformer secondary circuit while the primary side is energized. Ensure all CT blocks are shorted securely prior to removing wiring or the module.
  • Wiring Integrity: Route analog input signals through shielded twisted-pair cables to mitigate the effects of electromagnetic interference (EMI) and radio frequency interference (RFI) common in high-voltage substations.
  • Software Configuration: Following physical installation, connect via EnerVista UR software to map the new hardware matrix and verify that the ratio settings match the primary instrument transformers.
Key Features:
#CT/VT Module

What is the primary function of the enhanced diagnostics on this module?
The enhanced diagnostics utilize an internal algorithm to continuously verify the integrity of incoming analog signals, ensuring the reliability of the scaled voltage and current readings before processing.

Can the phase and ground CT inputs be configured for both 1A and 5A secondary ratings?
Yes, the module is engineered to accommodate standard 1A or 5A secondary current transformer inputs for both the three phase CT channels and the single ground CT channel.

How can an engineer access the diagnostic data generated by the module?
Diagnostic values and scaled analog measurements can be viewed directly through the liquid-crystal display on the front faceplate of the relay or remotely via the EnerVista UR software.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
