Omron NS12-TS01-V2 NS Series Programmable Terminal

Description

Integrating the NS12-TS01-V2 human-machine interface (HMI) into industrial automation systems provides operators with high-resolution visualization and intuitive touch control. This Omron NS Series programmable terminal features a 12.1-inch TFT color display, offering clear graphical representations of machine processes, real-time status updates, and interactive control options. Equipped with built-in Ethernet capabilities, it supports seamless integration into plant-wide host networks, facilitating reliable data transmission, PLC communications, and remote system monitoring.

Its robust mechanical construction allows for secure panel mounting in diverse industrial environments. Designed for long-term reliability in manufacturing, processing, and assembly lines, this terminal interfaces seamlessly with Sysmac controllers and standard PLCs to optimize supervisory control systems.

Features

• High-luminance 12.1-inch TFT color display with a resolution of 800 x 600 dots.
• Built-in Ethernet port for high-speed network integration, upload/download, and host communications.
• Durable resistive analog touchscreen facilitating highly responsive operator inputs.
• Sleek, industrial-grade ivory enclosure designed for clean-room and control cabinet mounting.
• Compatible with standard Omron programming software for efficient screen design and device configuration.

Applications

• Automotive assembly and robotic workcell monitoring
• Packaging, labeling, and material handling systems
• Water and wastewater treatment facility control consoles
• Food and beverage processing and batch monitoring
• Specialized CNC machine tool interfaces

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Panel Cutout: Mount the HMI in a clean, flat panel cutout, ensuring the waterproof packing seal is properly seated to prevent ingress of dust or moisture.
• Power & Grounding: Connect a stable 24 VDC power supply to the dedicated terminal. Ground the terminal separately to an independent class-3 ground (100 ohms or less) to minimize electromagnetic interference.
• Ventilation: Provide at least 100 mm of clearance space around the terminal inside the enclosure to allow natural convection and prevent heat buildup.
• Atmospheric Conditions: Avoid mounting the device in direct sunlight, highly dusty environments, or areas subject to corrosive chemical gases.
