Schneider Altivar VW3A1102 Variable Frequency Drives

Description

The VW3A1102 is a remote mounting kit specifically engineered for Altivar series variable speed drive graphic terminals. This door mounting kit enables the operator display to be installed on the front panel of an enclosure, providing an IP54 ingress protection rating that shields the terminal from dust and moisture in challenging industrial environments. The VW3A1102 allows for centralized control and real-time monitoring of drive parameters without requiring direct access to the interior of the cabinet.

Features

• Compatible with Altivar variable speed drive graphic terminals
• IP54 protection rating for enhanced environmental resistance
• Facilitates remote access and monitoring on enclosure doors
• Durable construction for industrial use

Applications

• Remote operation of variable frequency drives
• Cabinet-mounted HMI for motor control systems
• Industrial automation enclosures requiring external display access

Technical Specifications

Installation Guidelines

• Cutout Requirements: Ensure the enclosure door is prepared with the correct cutout dimensions as specified in the official drive manual to maintain the IP54 seal.
• Gasket Placement: Verify that the seal/gasket is properly seated between the mounting kit frame and the enclosure door to maintain the environmental rating.
• Securing: Tighten all mounting hardware evenly to ensure a secure, vibration-resistant fit against the panel surface.
• Cable Routing: Use the recommended remote cable lengths provided by the drive manufacturer to ensure signal integrity between the terminal and the variable speed drive.
