ABB GJR2395500R1210 83SR50R1210 Procontrol P14 Control Module

Description

The GJR2395500R1210 (ABB type designation 83SR50R1210) is a binary control module belonging to the Procontrol P14 control system series. Configured with 4 channels for binary control, the GJR2395500R1210 provides signal processing through a total of 16 digital input channels and 8 digital output channels (4 DI + 2 DO per channel). The 83SR50R1210 module is engineered for binary control and signal conditioning in power plant and industrial automation applications.

Features

• Features 4 channels for binary control, with 4 digital inputs and 2 digital outputs per channel.
• Incorporates a total of 16 digital input channels and 8 digital output channels (DX channel type).
• Configured as a compact plug-in I/O module for Procontrol P14 controller architectures.

Applications

• Drive control for reversible drives.
• Drive control for unidirectional drives.
• Drive control for actuators.
• Drive control for solenoid valves.
• Function group control.
• 3-step control.
• Signal conditioning.

Technical Specifications

Installation Guidelines

• Verify that the rack slot and system backplane power are de-energized before inserting or removing the module.
• Observe static discharge safety measures when handling the circuit card to avoid component degradation.
• Align the module with the card guides of the Procontrol P14 rack enclosure and press firmly to seat the backplane connection.
• Ensure proper terminal connection of external field wiring for binary input and output circuits according to system wiring diagrams.

Compliance and Certifications

• RoHS Information: Following EU Directive 2011/65/EU
• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
