ABB PM573-ETH 1SAP130300R0271 AC500 Controller Module

SKU 1SAP130300R0271

In stock

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: 1SAP130300R0271
Country of origin:Sweden
Product Type: Controller Modules
Barcode: 85371091
Payment: T/T, Western Union
Weight: 660g
Shipping port: Xiamen
Warranty: 12 months

Description

Engineered for demanding industrial automation applications, the PM573-ETH (part number 1SAP130300R0271) serves as a high-performance central processing unit within the ABB AC500 PLC platform. This robust controller is designed to manage complex logic processes, offering a 512 KB program memory capacity and seamless system expandability.

The unit features native Ethernet connectivity for efficient factory networking and remote monitoring, alongside two serial interfaces configurable for RS232 or RS485 communication protocols. A dedicated FieldBusPlug (FBP) slot allows for flexible fieldbus integration, while the integrated front-panel LCD display provides direct, real-time diagnostic feedback and configuration options. For reliable data logging, program transfer, and firmware updates, the controller is equipped with an easily accessible SD card slot.

Features

512 KB of onboard program and data memory for processing control logic.
Integrated RJ45 Ethernet interface supporting standard industrial network protocols.
Dual serial ports configurable for RS232 or RS485 serial communication.
Dedicated FieldBusPlug (FBP) port for versatile fieldbus adapter connections.
Front-panel LCD screen for localized status diagnostics and parameter configuration.
Integrated SD card slot for secure configuration backup and data storage.
Powered by a standard industrial 24 VDC supply voltage.

Applications

Water and wastewater management systems.
Power generation and auxiliary control systems.
Factory automation and machine-level control.
HVAC and building infrastructure control systems.

Technical Specifications

Manufacturer	ABB
Model / Article Number	PM573-ETH / 1SAP130300R0271
Series	AC500
Product Type	Programmable Logic Controller CPU
Program Memory	512 KB
Supply Voltage	24 VDC
Communication Interfaces	1x Ethernet (RJ45), 2x Serial (RS232/RS485), 1x FBP (FieldBusPlug)
Storage Slot	SD Card Slot
Display	Integrated LCD Display
Weight	0.66 kg
Commodity Code	85371091

Installation Guidelines

Mounting: Install the CPU module securely onto the designated AC500 terminal base on a standard DIN rail.
Wiring: Ensure all power connections use a stabilized 24 VDC source with appropriate overcurrent protection.
Grounding: Connect the functional earth connection on the terminal base directly to the system's low-impedance ground bus.
Ventilation: Maintain standard clearance distances above and below the module to permit natural convection cooling and prevent thermal buildup.

FAQ

What is the memory size of the ABB PM573-ETH controller?

The PM573-ETH (1SAP130300R0271) features 512 KB of dedicated program and data memory.

What communication ports are built into the 1SAP130300R0271 module?

The controller contains one RJ45 Ethernet port, two serial ports configurable for RS232 or RS485 communication, and one FieldBusPlug (FBP) connection interface.

Does this controller support local program storage and backups?

Yes, the front panel includes an integrated SD card slot designed for program storage, data logging, configuration backups, and firmware loading.

What power supply is required for the PM573-ETH?

The controller requires a standard industrial 24 VDC power supply connected through the compatible AC500 terminal base.
