ABB PP836A 3BSE042237R2 Panel 800 Key Panel

SKU PP836A 3BSE042237R2

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB

  • Product No.: PP836A 3BSE042237R2

  • Country of origin:Taiwan

  • Product Type: Operator Panel

  • Barcode: 85371091

  • Payment: T/T, Western Union

  • Weight: 1830g

  • Dimensions: 28.5 cm x 17.6 cm x 6 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The PP836A 3BSE042237R2 is an industrial operator interface unit designed to facilitate plant-floor monitoring and manual command execution within centralized automation architectures. Operating as a Panel 800 Key Panel, this terminal integrates physical tactile keys alongside a 6.5 inch active thin-film transistor display panel to manage visualization and system interaction tasks simultaneously. The display screen structures process variables, technical values, and system warnings into clear graphic layouts and text lines. Optimized for complete systemic compatibility with ABB System 800xA and Compact Product Suite infrastructures, the PP836A 3BSE042237R2 coordinates continuous field variables communication while acting as a robust operator station within process engineering landscapes.

Features

  • Incorporates a dedicated 6.5 inch active displaying screen paired with a responsive physical key configuration for structured operational maneuvering
  • Delivers multi-color text data and schematic graphics tracking through a balanced 640x480 pixel display matrix
  • Functions inside multiple standard platform groups including Panel 800 version 4.1, 5.0, and 5.1 control system accessories
  • Engineered using a robust industrial enclosure frame optimized to withstand steady machinery environments

Applications

  • Distributed terminal interface management inside Compact Product Suite automation setups
  • Local operator monitoring and manual instruction entry in System 800xA operations

Technical Specifications

Parameter Value
Manufacturer ABB
Model Designation PP836A
Product ID 3BSE042237R2
ABB Type Designation PP836A
Display Type 6.5 inch TFT Key Panel
Resolution 640x480 pixels
Supported Content Graphics & Text, Color
Configuration Utility Requires Panel Builder 800 version 5
Country of Origin Taiwan, Province Of China (TW)
Customs Tariff Number 85371091
Product Net Weight 1.83 kg

Installation Guidelines

  • Enclosure Installation: Secure the module into its designated console front opening using recommended structural mounting clips to maintain balanced mechanical fixing.
  • Frontal Protection: To protect the front key rows and screen surface from scratching or moisture ingress, it is recommended to install the dedicated accessory RX836 Key Cover over the front layout.
  • Firmware Configuration: Ensure the application engineer programs the user interface database using the Panel Builder 800 version 5 platform prior to downloading the initial deployment configuration.

FAQ

Which software version is necessary to configure this operator terminal?

The device requires Panel Builder 800 version 5 as its mandatory development utility to load and structure project screens.

What are the core technical display properties of this panel?

The module features a 6.5 inch TFT color key panel carrying a native resolution of 640x480 pixels that displays both graphics and structured text.

Is there any specific field protection accessory recommended for this module?

To safeguard the front interface frame and tactile components, the use of the RX836 Key Cover is recommended during regular factory service.
