ABB PP883 3BSE092979R1 Panel 800 Touchscreen Panel

SKU PP883 3BSE092979R1

In stock

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: PP883 3BSE092979R1
Country of origin:Sweden
Product Type: Touchscreen Panel
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 2600g
Dimensions: 340 x 242 x 57 mm
Shipping port: Xiamen
Warranty: 12 months

Description

The PP883 (Article number 3BSE092979R1) is a standard human-machine interface (HMI) built to deliver multi-protocol connectivity and flexible machine-level tracking across automated processing loops. This Touchscreen Panel features a 12.1-inch widescreen TFT/LED layout, engineered to integrate seamlessly into the ABB Ability System 800xA hardware selector framework or interface with diverse multi-brand controller nodes. Running on an ARM9 processor (1 GHz) with 1 GB of main memory, the module executes complex visualization layouts using 1.5 GB of dedicated application flash storage within its onboard 2 GB SSD. Encased in a lightweight, rugged housing, its front face utilizes a resistive touch matrix optimized for factory environments requiring continuous dust, moisture, and chemical protection.

Features

High-Resolution Widescreen Display: Equipped with a 1280 x 800 pixel TFT/LED display featuring bright color rendering and integrated dimming support.
Resistive Touch Interface: Offers tactile operational interaction and high navigation accuracy even when users wear heavy industrial gloves.
Open Software Architecture: Fully compatible with the .NET framework and the Panel Builder 800 tool, enabling straightforward programming and cross-platform communication.
Pre-Commissioning Simulation: Provides the operational capability to simulate and run user applications directly from the configuration software before live installation.
Ruggedized Mechanical Build: Constructed inside a dust-tight diecast, powder-coated aluminum casing rated to withstand steady mechanical vibration and impact shock.

Applications

Marine Automation, Vessel Propulsion Monitoring, and Offshore Drill Rig Systems
Distributed Control System (DCS) Human-Machine Interfacing and Status Visualization
Multi-Brand PLC Network Integration and Centralized Production Line Monitoring

Technical Specifications

Display and Performance

Parameter	Value
Display Type	Touch
Display Size	12.1 inch
Display Resolution / Ratio	1280 x 800 pixels
Brightness	400 cd/m2
Dimming	Yes
Interaction Type	Resistive touch
Processor	ARM9 (1 GHz)
Main Memory	1 GB
External Storage Media	2 GB SSD (1.5 GB free for application storage)
Realtime Clock	Yes

Electrical and Mechanical

Parameter	Value
Manufacturer	ABB
Article Number (Model)	3BSE092979R1 (PP883)
Category	Standard
Power Supply	+24 V DC (18 to 32 VDC)
Power Consumption	28.8 W
Housing Material	Diecast, powder-coated aluminum
Dimension WxHxD	340 x 242 x 57 mm
Cut-out Dimension WxH	324 x 226 mm
Mounting Depth (with clearance)	49 (149) mm
Weight	2.6 kg
Mounting Options	Panel Mount, VESA 75 x 75

Environmental and Limits

Parameter	Value
Operating Temperature	-10 to +60 degC
Storage Temperature	-20 to +70 degC
Relative Operating Humidity	5% - 85% non-condensed
Protection Rating	Front IP65, NEMA 4X/12, UL Type 4X/12; Rear IP20
Vibration and Shock	1G / 15 G
Hazardous Area Rating	No

Connections/Interfaces

Interface Port / Connector	Function
Ethernet (2 x Shielded RJ-45)	Dual 10/100 Base-T ports for network segregation, local communication, and remote access.
USB (2 x USB 2.0)	Dual host interfaces supplying 500mA per port for external accessories or firmware updates.
Serial Port (1 x RS232)	Point-to-point serial communication channel for localized device data linkage.
Serial Port (1 x RS422/485)	Differential multi-drop serial interface for legacy master/slave networks.
Serial Port (1 x RS485)	Independent port active exclusively when the secondary serial channel (COM 2) is assigned as RS485.

Installation Guidelines

Cut-Out Dimensions Alignment: Ensure the mounting panel opening is pre-cut to exactly 324 x 226 mm prior to inserting the unit.
Clearance Depth Allocation: Allow for a full installation depth clearance of 149 mm within the enclosure to facilitate proper strain relief and cable routing.
Front Sealing Compression: Secure all panel mount retaining clips evenly to ensure uniform gasket compression, establishing an IP65 boundary against external moisture.
Power Feed Verification: Provide a clean, external +24 V DC source, maintaining voltage tracking strictly between 18 and 32 VDC.

Compliance and Certifications

CE-marking: CE, FCC, KCC
UL Certification: UL 61010-2-201
Marine Approvals: DNV, KR, GL, LR, ABS, CCS
RoHS Directive: EU ROHS, UAE ROHS, CN ROHS
WEEE Compliance: DIRECTIVE/2012/19/EU

FAQ

What is the specified ambient temperature range for safe operation of this panel?

The approved ambient operating temperature for this hardware module spans from -10 degC to +60 degC.

Does this HMI support application simulation before deploying it to the hardware?

Yes, user projects can be simulated and executed directly from the Panel Builder 800 software tool environment prior to physical deployment.

Under what specific condition can the independent secondary RS485 port be utilized?

The independent RS485 serial port is active and accessible only when the COM 2 port configuration is set to RS485 mode.
