Altivar 58 ATV58HU41N4Z | Schneider Electric | Variable Frequency Drive

Description

The ATV58HU41N4Z is an adjustable speed drive from the Schneider Electric Altivar 58 series. Designed for industrial motor control, this unit provides a power output of 2.2 kW and features an integrated heat sink for effective thermal management. The drive is equipped with a built-in Class A EMC filter to mitigate electromagnetic interference, ensuring compliance with industrial standards in sensitive electrical environments.

Features

• Adjustable speed control for 2.2 kW motors
• Integrated heat sink for robust thermal dissipation
• Built-in Class A EMC filter for reduced electromagnetic noise
• Compact design optimized for cabinet mounting

Technical Specifications

Installation Guidelines

• Cabinet Mounting: Ensure the drive is mounted vertically in a clean, ventilated enclosure. Adhere to the minimum clearance distances specified in the original technical documentation to allow the integrated heat sink to function correctly.
• EMC Compliance: Given the built-in Class A EMC filter, ensure proper grounding of the drive chassis to the cabinet backplane using short, low-impedance conductors.
• Wiring: Keep motor cables and control signal cables segregated to prevent induced noise on sensitive input circuits.
• Status: Please be advised that this unit is currently classified as Obsolete. It is recommended to verify compatibility with modern replacement drives in the Altivar range if implementing new system designs.

Compliance and Certifications

• Commodity Code: 85044095
• Export Control Regulations (ECCN): N
