BECKHOFF C3340-0070 19-inch Panel PC

Description

Built for direct integration into standard 19-inch rack enclosures, the BECKHOFF C3340-0070 is a high-performance industrial 19-inch Panel PC engineered for complex visualization, control, and computational tasks in demanding factory environments. This system features a rugged stainless steel-based housing paired with an aluminum front bezel and a lockable front flap to protect internal components and drives from unauthorized access and environmental contaminants.

The unit integrates a 15-inch display with a resolution of 1024 x 768 pixels, supplemented by an integrated front keyboard containing 12 function keys, cursor controls, numeric input, and 10 dedicated PLC keys equipped with status LEDs. Under the hood, the system is designed around an ATX motherboard supporting 6th and 7th generation Intel processors, extensive RAM expandability, and multiple PCIe and PCI slots, allowing seamless integration of fieldbus cards and specialized industrial communication modules.

Features

• Rugged physical construction featuring a stainless steel chassis and an aluminum front plate.
• Integrated front keyboard with 12 function keys, full numeric keypad, cursor keys, and 10 custom slide-in label PLC keys with built-in LEDs.
• High-density motherboard supporting scaling options from Intel Celeron up to Intel Core i7 processors.
• Versatile expansion options with multiple full-length PCI and PCIe slots for legacy and modern system integration.
• Built-in SATA RAID 1 controller for hardware-level data redundancy and system reliability.
• Excellent environmental resilience, offering IP65 protection on the front face.

Applications

• Automotive manufacturing and assembly line master control.
• Power generation and distribution facility monitoring.
• Process technology and chemical plant supervisory control.
• High-performance testbench and machine tool operation.

Technical Specifications

Expansion Slots

Connections and Interfaces

Installation Guidelines

• Mounting: Unit is designed to be installed into a standard 19-inch racking panel. Ensure the mounting rack can support the 18.5 kg dry weight of the PC.
• Cooling: Maintain sufficient clearance at the rear of the unit to allow the exhaust fan to maintain airflow. Internal temperature must not exceed 55 degC during operation.
• Power & Grounding: Connect the chassis ground stud securely to the cabinet common ground rail. Use verified, clean power input sources matching the technical rating plate (24 V DC or 100-240 V AC).
