Manufacturer: BECKHOFF
Product No.: CX2020-N031
Country of origin:Germany
Product Type: Basic CPU module
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
The CX2020-N031 (CX2020-N031) is a specialized interface module designed to expand the serial communication capabilities of the Beckhoff CX2000 embedded PC series. Engineered for critical industrial applications—such as power distribution, energy management, and automated manufacturing—this module facilitates seamless integration between centralized control systems and RS485-based field hardware. By providing a dedicated, high-performance serial gateway, it ensures stable and deterministic data transfer, ultimately minimizing communication latency and system downtime in industrial automation networks.
This hardware extension provides a reliable RS485 connection via a 9-pin D-sub socket. The module is factory-optimized for end-of-line applications, featuring internal termination circuitry that is permanently enabled to maintain signal integrity over long transmission distances. The implementation strictly adheres to a "no-echo" configuration, which simplifies data processing by preventing the reflection of transmitted signals back into the controller, thereby increasing the effective bandwidth available for external device polling. This modular approach allows for rapid deployment in complex control topologies without requiring external bus conditioning hardware.
| Feature | Specification |
| Model | CX2020-N031 |
| Brand | BECKHOFF |
| Device Type | Basic CPU Module (Serial Interface) |
| Interface Type | RS485 |
| Connector | 9-pin D-sub socket |
| Bus Configuration | End point (termination on) |
| Echo Mode | Disabled |
| Compatibility | CX2000 Series Embedded PCs |
| Weight | Approx 150 g |
Is it possible to disable the internal termination on this module?
The CX2020-N031 is specifically configured as an end-point interface with fixed internal termination, making it best suited for the final device on an RS485 bus segment.
Which control platforms are compatible with this module?
This module is designed for integration with the Beckhoff CX2000 series embedded PC lineup, serving as a modular expansion for serial communication.
What cabling is recommended for the RS485 interface?
For optimal performance, use a shielded, twisted-pair cable designed for RS485 communication. Ensure the cable shield is grounded correctly at the entry point to mitigate electromagnetic interference.
Does this module require specific TwinCAT driver settings?
Yes, after physical installation, configure the serial port parameters—such as baud rate and parity—within the TwinCAT system environment to match the requirements of your connected field device.
Secure Connectivity: Ensure the 9-pin D-sub connector is fully seated and the housing screws are tightened. This prevents mechanical stress on the PCB headers during high-vibration operations, which is critical for maintaining consistent signal quality in industrial settings.
Grounding Protocols: While the RS485 interface is robust, avoid establishing multiple ground points. Connect the cable shield to the protective earth (PE) at the control cabinet terminal block to prevent ground loops that could otherwise lead to signal corruption or hardware failure.
Thermal Management: The module is designed to operate within the thermal envelope of the CX2000 host system. To prevent overheating, ensure that the ventilation paths on the main CPU module remain unobstructed, allowing sufficient airflow across the interface boards.
