BECKHOFF CX9020-N031 Embedded PC

SKU CX9020-N031

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: CX9020-N031
Country of origin:Germany
Product Type: Embedded PCs
Payment: T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

Description

The BECKHOFF CX9020-N031 is a compact, DIN-rail-mountable Embedded PC designed for mid-range PLC and Motion Control applications. Powered by an ARM Cortex-A8 processor, this basic CPU module integrates a control unit with direct I/O support and built-in communication interfaces for industrial environments.

The CX9020-N031 variant is factory-configured with a dedicated RS485 system interface. This interface features a 9-pin D-sub socket configured as an end point with active termination and no echo, allowing direct serial communication with external field devices, legacy controllers, or peripheral instrumentation.

With its automatic bus detection capability, the unit directly interfaces with both Beckhoff Bus Terminals (K-bus) and EtherCAT Terminals (E-bus). This dual-bus support enables flexible, scalable control architectures without requiring separate bus coupler modules.

Features

ARM Cortex-A8 processor (1 GHz) for stable industrial control execution
Factory-integrated RS485 serial interface (9-pin D-sub socket, end point configuration with active termination and no echo)
Dual-system I/O bus interface with automatic detection of E-bus (EtherCAT Terminals) and K-bus (Bus Terminals)
Built-in dual RJ45 Ethernet interfaces with an internal switch
Compact housing design optimized for standard DIN-rail mounting

Applications

Decentralized machine control and modular automation systems
Serial communication and peripheral device integration via RS485 protocols
Building automation, HVAC control, and infrastructure monitoring
Compact motion control and localized PLC installations

Technical Specifications

General

Parameter	Specification
Manufacturer	BECKHOFF
Exact Model	CX9020-N031
Product Type	Embedded PC / Basic CPU Module
Processor	ARM Cortex-A8, 1 GHz

Interfaces and Connectivity

Parameter	Specification
System Interface	RS485 (9-pin D-sub socket)
RS485 Configuration	End point, without echo, active termination
Network Interfaces	2 x RJ45 (switched)
I/O Connection	E-bus (EtherCAT Terminals) or K-bus (Bus Terminals) with automatic recognition

Electrical and Mechanical

Parameter	Specification
Power Supply	24 V DC
Mounting Method	35 mm DIN rail (EN 60715)

Connections / Interfaces

Interface or Terminal	Function
RS485 (D-sub, 9-pin)	Serial interface configured as an end point with termination active, no echo
RJ45 Ports	Ethernet network connections with integrated switch functionality

Installation Guidelines

Verify the exact model and specification matches your system requirements before installation.
Ensure the entire control cabinet and power supply are de-energized before mounting.
Snap the Embedded PC onto a clean, grounded 35 mm DIN rail (EN 60715).
Connect the 24 V DC power supply to the designated power terminals.
Connect the RS485 communication lines to the 9-pin D-sub socket, ensuring correct shielding.
Attach the compatible EtherCAT Terminals (E-bus) or Bus Terminals (K-bus) directly to the right side of the module.
Energize the system and perform initial software configuration and system commissioning.

FAQ

What is the main interface configuration on the BECKHOFF CX9020-N031?

The BECKHOFF CX9020-N031 is equipped with an integrated RS485 system interface via a 9-pin D-sub socket, configured as an end point with active termination and no echo.

Does the BECKHOFF CX9020-N031 support both EtherCAT and standard Bus Terminals?

Yes, the BECKHOFF CX9020-N031 features automatic bus recognition that directly supports both E-bus (EtherCAT Terminals) and K-bus (standard Bus Terminals) direct connections.

What processor powers the BECKHOFF CX9020-N031 Embedded PC?

The BECKHOFF CX9020-N031 Embedded PC is powered by an ARM Cortex-A8 processor running at a clock frequency of 1 GHz.

What are the power requirements for the BECKHOFF CX9020-N031?

The BECKHOFF CX9020-N031 requires a nominal 24 V DC power supply for standard operation.
