Manufacturer: BECKHOFF
Product No.: ELM3102-0000
Country of origin:Germany
Product Type: EtherCAT Terminals
Payment: T/T, Western Union
Weight: 350g
Dimensions: 30 mm x 100 mm x 95 mm
Shipping port: Xiamen
Warranty: 12 months
The BECKHOFF ELM3102-0000 is an advanced EtherCAT Terminal featuring two analog input channels designed for precise current measurement. Engineered within a robust zinc die-cast metal housing, this high-precision terminal supports differential signal types and delivers a 24-bit resolution with a maximum sampling rate of 20 ksps per channel simultaneously. It integrates seamlessly into EtherCAT automation networks, providing accurate data acquisition with distributed clocks supporting synchronization accuracy well below 1 microsecond.
Equipped with sophisticated internal processing features such as ExtendedRange 107 percent, free numeric filters, TrueRMS calculation, integrator and differentiator functions, non-linear scaling, and PeakHold, the BECKHOFF ELM3102-0000 accommodates demanding industrial measurement applications. Connection is facilitated via push-in spring actuation technology using service plugs, supporting solid and fine-stranded conductors for efficient installation on standard 35 mm DIN rails.
| Parameter | Specification |
|---|---|
| Manufacturer | BECKHOFF |
| Exact Model | ELM3102-0000 |
| Product Type | EtherCAT Terminal |
| Housing Material | Zinc die-cast |
| Design Form | Metal housing with signal LEDs |
| Parameter | Specification |
|---|---|
| Number of Channels | 2 |
| Technology | Current measurement |
| Signal Type | Differential |
| Measuring Range | ±20 mA |
| Resolution | 24 bit (incl. sign) |
| Max. Sampling Rate | 20 ksps / 50 µs per channel (simultaneously) |
| Oversampling Factor | n = 1…100 selectable (max. 20 ksamples/s) |
| Internal Resistance | 150 ohm (current) |
| Measuring Error | Typ. < ±100 ppm / ±0.01 % in some measuring ranges (relative to full scale) |
| Temperature Coefficient | Typ. < 10 ppm/K |
| Electrical Isolation | 707 V DC (type test) channel/bus, channel/SGND |
| Current Consumption E-Bus | Typ. 340 mA |
| Thermal Dissipation | Typ. 3 W |
| Parameter | Specification |
|---|---|
| Connection Type | Push-in, service plug 2-pin |
| Conductor Cross-Section Solid (s) | 0.2…1.5 mm² (AWG 24…14) |
| Conductor Cross-Section Stranded (st) | 0.2…1.5 mm² (AWG 24…14) |
| Conductor Cross-Section with Ferrule (f) | 0.25…0.75 mm² (AWG 24…14) |
| Stripping Length | 8…9 mm |
| Parameter | Specification |
|---|---|
| Dimensions (W x H x D) | 30 mm x 100 mm x 95 mm |
| Weight | Approx. 350 g |
| Mounting | On 35 mm DIN rail conforming to EN 60715 with lock |
| Operating Temperature Range | -25 to +60 Celsius |
| Storage Temperature Range | -40 to +85 Celsius |
| Approvals / Markings | CE, UL |
