BECKHOFF IP2002-B528 Fieldbus Box Digital Output Module

SKU IP2002-B528

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: IP2002-B528
Country of origin:Germany
Product Type: Fieldbus Boxes
Payment: T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

Decentralized automation architectures utilize the IP2002-B528 digital output module to interface directly with actuators in demanding industrial environments. This high-protection BECKHOFF Fieldbus Box features 8 digital outputs, handling binary control signals with a maximum load capacity of 0.5 A per channel. Integrated with a DeviceNet interface and an onboard T-connector, this module simplifies bus topology design by enabling direct daisy-chaining of the network cable without external splitters.

Housed in a robust, fully sealed enclosure, the IP2002-B528 is designed for cabinet-free installation directly on machinery. This eliminates the need for terminal boxes, reduces wiring complexity, and optimizes signal integrity across long distances. The short-circuit proof outputs and clear LED diagnostics ensure high operational reliability and minimal downtime during maintenance cycles.

Features

8 digital outputs rated at 24 V DC, 0.5 A per channel.
Integrated DeviceNet interface with an onboard T-connector for simplified network looping.
Robust IP67 ingress protection rating for installation directly in wet, dusty, or harsh environments.
Connection of field actuators via standard, vibration-resistant M12 screw connectors.
Short-circuit protected outputs with individual channel diagnostic indicators.
Compact, lightweight design suitable for mounting directly on moving machine elements.

Applications

Automotive assembly lines and robotic cells
Material handling systems and industrial conveyors
Packaging machinery and automated sorting systems
Decentralized process equipment requiring IP67 local I/O distribution

Technical Specifications

CategoryTechnical ParameterValue

Manufacturer	BECKHOFF	IP2002-B528
Protocol / Fieldbus	DeviceNet	M12, integrated T-connector
Number of Outputs	8 digital outputs	24 V DC (-15% / +20%)
Nominal Voltage	24 V DC (-15% / +20%)	0.5 A (short-circuit proof)
Load Type	Ohmic, inductive, lamp load	M12 screw connector (2-channel allocation)
Operating Temperature	0 to 55 degC	Storage Temperature
IP Rating	IP67	CE

Connections and Interfaces

Connection Type	Function / Allocation
DeviceNet In / Out	M12 male / female, integrated T-connector for signal looping
I/O Channels 1 to 8	4 x M12 female sockets (2 outputs per socket)
Power Supply	M8 male connector (control voltage and load voltage)

Installation Guidelines

Securely mount the module onto flat surfaces using two M4 screws through the integrated mounting holes.
Apply the specified tightening torque to all M12 and M8 connectors to guarantee a complete IP67 hermetic seal.
Ensure grounding continuity by securing the ground connection point to the machine frame or functional earth.
Avoid routing the fieldbus and actuator cables parallel to high-voltage power lines to mitigate electromagnetic interference.

Compliance and Certifications

CE

FAQ

What is the primary function of the Beckhoff IP2002-B528?

The Beckhoff IP2002-B528 is an IP67-rated decentralized Fieldbus Box that provides 8 digital outputs (24 V DC, 0.5 A) and communicates via a DeviceNet network.

What are the advantages of the integrated T-connector on this module?

The integrated T-connector allows the DeviceNet network line to be directly daisy-chained from one Fieldbus Box to another, reducing the need for external T-junctions and additional cabling.

Is a protective cabinet required to mount the IP2002-B528?

No, because the IP2002-B528 features an IP67-rated enclosure, it can be mounted directly onto machinery in harsh environments without an electrical cabinet.

Are the outputs protected against short circuits?

Yes, all 8 digital outputs on the IP2002-B528 are fully short-circuit protected and include diagnostic status LEDs.
