Decentralized field automation requirements are directly addressed by the IP5009-B528, a high-performance DeviceNet fieldbus box engineered by Beckhoff for direct mounting in demanding industrial environments. This station connects digital and analog peripheral signals directly to DeviceNet networks without requiring a protective control cabinet. By utilizing integrated M12 tee-connector ports and M8 power feed-through interfaces, this module enables efficient line-topology wiring directly on the machinery.
The module supports configuration flexibility through either the Beckhoff KS2000 software suite or directly via the master controller using explicit messaging. The integrated electronics dynamically adapt to network transfer rates up to 500 kbaud. Electrical isolation of 500 V between the control voltage and the fieldbus line provides robust protection against transient noise and grounding loops, securing reliable I/O data transmission across varying plant distances.
| BECKHOFF |
| IP5009-B528 |
| DeviceNet |
| Automatic detection up to 500 kbaud |
| 1 x M12 plug (5-pin), 1 x M12 socket (5-pin) (tee-connector integrated) |
| Shielded copper cable, with power supply, typ. 2 x 2 x 0.25 mm² |
| 24 V DC (-15 % / +20 %) |
| According to connected I/O type |
| Feed: 1 x M8 male socket (4-pin); Downstream: 1 x M8 female socket (4-pin) |
| 45 mA + current consumption of sensors (max. 0.5 A) |
| Control voltage/fieldbus: 500 V; Control voltage/I/O: according to I/O type |
| Bit strobe, polling, cyclic, change of state (COS) |
| 0 to +55 degC |
| -25 to +85 degC |
| Conforms to EN 60068-2-6 / EN 60068-2-27 |
| Conforms to EN 61000-6-2 / EN 61000-6-4 |
| IP65/66/67 (conforms to EN 60529) |
| Variable |
| 2.0 kg |
| Connection Interface | Connector Type | Function |
|---|---|---|
| Bus Input | M12 Plug, 5-pin | DeviceNet upstream fieldbus network connection |
| Bus Output | M12 Socket, 5-pin | DeviceNet downstream connection (integrated T-connector) |
| Power Input | M8 Male Socket, 4-pin | Feed control voltage (24 V DC) and sensor/actuator power |
| Power Output | M8 Female Socket, 4-pin | Downstream control and load voltage loop-through |
