BECKHOFF KM1002-0004 Bus Terminal Module

SKU KM1002-0004

In stock

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: KM1002-0004
Country of origin:Germany
Product Type: Bus Terminal module
Payment: T/T, Western Union
Weight: 2000g
Dimensions: 26.5 mm x 100 mm x 71 mm
Shipping port: Xiamen
Warranty: 12 months

The KM1002-0004 is a high-density, 16-channel digital input Bus Terminal module engineered by BECKHOFF. Designed for efficient integration into automation systems, this module captures 24 V DC binary control signals and transmits them to the higher-level controller via the K-bus. Featuring a compact design with pluggable 3-wire connectors and integrated LEDs, the KM1002-0004 simplifies wiring and status monitoring in space-constrained industrial control cabinets.

Features

16 digital input channels arranged in two 8-channel groups
24 V DC nominal voltage with Type 1 input specification (EN 61131-2)
Integrated 3.0 ms input filter for signal debouncing
500 V electrical isolation between the K-bus and field potential
Pluggable 3-wire connection technology with status LEDs
Compact form factor with double slot and key connection for easy DIN rail assembly

Applications

Distributed I/O acquisition in PLC and automation systems
Industrial sensor monitoring (proximity switches, limit switches)
Machine control and status signaling
Factory automation environments requiring high-density input points

Technical Specifications

Category	Specification
Manufacturer	BECKHOFF
Model	KM1002-0004
Number of Inputs	16 (2 x 8)
Nominal Voltage	24 V DC (-15 %/+20 %)
Input Filter	typ. 3.0 ms
Input Current	typ. 5 mA
Electrical Isolation	500 V (K-bus/field potential)
Operating Temperature	0 to +55 degC
Storage Temperature	-25 to +85 degC
Dimensions (W x H x D)	26.5 mm x 100 mm x 71 mm
Weight	approx. 110 g
Protection Rating	IP20

Ordering Information

Model	Description
KM1002-0000	16-channel digital input, 24 V DC, 3 ms, without connector
KM1002-0001	16-channel digital input, 24 V DC, 3 ms, 1-wire connector
KM1002-0002	16-channel digital input, 24 V DC, 3 ms, 1-wire connector with LEDs
KM1002-0004	16-channel digital input, 24 V DC, 3 ms, 3-wire connector with LEDs

Installation Guidelines

Mount the module onto a 35 mm DIN rail (EN 60715) using the integrated lock.
Utilize the double slot and key connection to ensure stable side-by-side mounting.
Wiring: Use solid or stranded wire with a cross-section of 0.08 to 1.5 mm2; ensure a stripping length of 8 mm.
Maintain an operating environment between 0 and +55 degC.
Ensure installation is within an IP20-compliant enclosure to prevent contamination.

Compliance and Certifications

CE
