Bently Nevada 330102-00-12-05-02-05 3300 XL 8 mm Proximity Probe

Only 6 item(s) left in stock

Manufacturer: Bently Nevada
Product No.: 330102-00-12-05-02-05
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

View full details

Description

The 330102-00-12-05-02-05 is a high-precision 3300 XL 8 mm proximity probe configuration featuring an armored 3/8-24 UNF steel probe body, designed for non-contact eddy-current displacement measurement. This specific unit is configured with 0.0 in unthreaded length (Option 00), 1.2 in case length (Option 12), and a 0.5 m system length (Option 05). It utilizes a standard Miniature ClickLoc coaxial connector (Option 02) and includes CSA, ATEX, and IECEx hazardous area approvals (Option 05).

This probe is a critical component of the 3300 XL 8 mm Proximity Transducer System, used extensively for monitoring vibration and axial position on critical rotating machinery such as turbines, compressors, and pumps. The armored cable design provides enhanced mechanical protection against abrasion and harsh industrial environments. When integrated into the monitoring chain with a compatible 3300 XL Proximitor sensor and extension cable, it delivers reliable and repeatable position and vibration data for machinery protection.

Features

3/8-24 UNF threaded probe body with armor for improved mechanical durability.
Option 00: 0.0 in unthreaded length configuration.
Option 12: 1.2 in overall case length.
Option 05: 0.5 m total system length.
Option 02: Miniature coaxial ClickLoc connector with standard cable type.
Option 05: Hazardous area agency approvals including CSA, ATEX, and IECEx.
Compatible with 3300 XL 8 mm Proximitor sensors and extension cables.
Designed for critical rotating machinery vibration and axial position measurements.

Applications

Turbine and compressor shaft vibration monitoring.
Rotor axial position and displacement measurement.
Industrial machinery protection systems.
Hazardous area environments requiring CSA/ATEX/IECEx compliance.
High-reliability requirements in power generation and petrochemical facilities.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330102-00-12-05-02-05	3300 XL 8 mm Proximity Probe, 3/8-24 UNF, Armored
A - Unthreaded Length	00	0.0 in
B - Case Length	12	1.2 in
C - Total Length	05	0.5 meter
D - Connector/Cable	02	Miniature ClickLoc, standard cable
E - Agency Approval	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330102-00-12-05-02-05
Probe Diameter	8 mm
Thread Size	3/8-24 UNF
Case Length	1.2 in
Unthreaded Length	0.0 in
Total System Length	0.5 meter
Cable Type	Standard, Armored
Connector Type	Miniature ClickLoc Coaxial
Hazardous Area Approvals	CSA, ATEX, IECEx
Operating Temperature	-51 degC to +177 degC
Material	AISI 303 or 304 Stainless Steel

Compliance and Certifications

This product is certified for use in hazardous areas under CSA, ATEX, and IECEx standards. Compliance ensures suitability for critical machinery protection in explosive or potentially hazardous atmospheres as defined by specific regional agency certifications.

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Proximity Probe	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the 00 code in the unthreaded length segment mean?

The 00 code indicates a 0.0 in unthreaded length, meaning the threading extends to the maximum allowable length along the probe case.

Is this probe armored?

Yes, the 330102 series is specifically designed with armored cabling to provide extra mechanical protection for the lead wire in demanding industrial settings.

Can I use this 0.5 m probe with any Proximitor sensor?

No, the probe length is specific to the system design. This 0.5 m probe is designed for use with the corresponding 0.5 m Proximitor sensor system. Ensure your extension cable and probe lengths sum correctly for the sensor calibration.

What certifications come with the 05 approval option?

The 05 option provides CSA, ATEX, and IECEx hazardous area approvals, making the probe suitable for use in explosive atmospheres.
