Bently Nevada 330180-X1-05 MOD:145004-63 3300 XL Proximitor Sensor

Description

The 330180-X1-05 MOD:145004-63 is a 3300 XL Proximitor Sensor designed for integration with 3300 XL 8 mm proximity transducer systems. This component acts as the signal conditioning interface between the proximity probe and the monitoring system, providing a proportional voltage output corresponding to the distance between the probe tip and the observed conductive surface.

This specific configuration, identified by the MOD:145004-63 suffix, includes factory-applied modifications tailored for specialized application requirements within machinery protection chains. It maintains compatibility with standard Bently Nevada 3300 XL components, including extension cables and 8 mm probes, ensuring consistent eddy-current displacement measurement performance for critical rotating assets such as turbines, compressors, and pumps.

Features

• Supports 3300 XL 8 mm proximity transducer system architectures
• Voltage output proportional to shaft vibration and axial position
• Advanced signal processing for RFI/EMI immunity
• DIN rail or panel mounting configurations (refer to specific system installation drawings)
• Option 05: CSA, ATEX, and IECEx hazardous area certifications
• Factory modified configuration (MOD:145004-63)

Applications

• Radial vibration monitoring on centrifugal compressors
• Axial position (thrust) measurement on steam and gas turbines
• Rotor speed and phase reference measurements
• General rotating machinery protection in hazardous environments

Ordering Information

Technical Specifications

Installation Guidelines

The Proximitor sensor must be installed in a protected environment, such as a Bently Nevada approved housing, to prevent exposure to moisture and corrosive agents. When routing signal cables, maintain separation from high-voltage AC lines to minimize electromagnetic interference. Ensure that the total system length (probe + extension cable) matches the calibrated length for this Proximitor sensor.
