General Electric DS200TCTGG1AFF Mark V Simplex Trip Board

SKU DS200TCTGG1AFF

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: General Electric
  • Product No.: DS200TCTGG1AFF
  • Origin United States
  • Product Type: Simplex Trip Board
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.32 kg
  • Dimensions: 28.8cm x 7.2cm x 3.8cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Quantity

Product Description

Description

The DS200TCTGG1AFF acts as a core hardware component within the Mark V Turbine Control System Series. As a Simplex Trip Board, this unit is engineered to manage specific trip and protection functionalities for turbine systems. The device is a domestically manufactured printed circuit board that features a normal style of coating assembly, ensuring long-term hardware reliability in standard operating environments. It integrates an array of plug-in relays and heavy-duty multi-pin connectors to distribute control and trip signals reliably.

Features

  • Equipped with 21 sequential plug-in relays labeled from K1 through K21.
  • Relays are physically secured using integrated metal retention straps.
  • Features three 50-pin connectors and two 12-pin connectors for comprehensive system interfacing.
  • Built with a normal style of PCB protective coating.

Applications

  • General Electric Mark V Turbine Control Systems
  • Simplex configuration trip management and protection loops
  • Industrial gas and steam turbine control automation

Technical Specifications

Parameter Specification
Manufacturer General Electric
Series Mark V
Part Number DS200TCTGG1AFF
Functional Acronym TCTG
Functional Description Simplex Trip Board
PCB Coating Normal Coating
Functional Revision 1 A
Functional Revision 2 F
Artwork Revision F

Connections/Interfaces

Connector Pin / ID Function
JLY 50-Pin Interface Connector
JLX 50-Pin Interface Connector
JLZ 50-Pin Interface Connector
JN 12-Pin Interface Connector
JM 12-Pin Interface Connector

Installation Guidelines

  • Power Isolation: Disable all power supplies by disconnecting the relevant fuses or alternative isolation devices before servicing. Always use a verified voltage testing device to confirm the absence of electric current inside the drive prior to touching components.
  • Cable Mapping: Explicitly diagram and label all cable locations and routing designations before disconnection to guarantee accurate reinstallation.
  • Relay Removal: Detach the securing metal strap from the connector base before pulling the relay straight out of its socket.
  • Relay Insertion: Align the replacement relay precisely with the connector socket, press it firmly into place, clip one end of the metal strap to the connector, route the strap over the top of the relay, and clip it securely to the opposite side of the connector.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many plug-in relays are populated on the board?
The board is populated with 21 plug-in relays, which are sequentially designated starting from K1 up to K21.
What types of cable connectors are available on the device?
The device features a total of five connectors: three 50-pin connectors designated as JLY, JLX, and JLZ, and two 12-pin connectors designated as JN and JM.
What is the procedure for securing a replacement relay into its socket?
Align the relay with the connector, press it down, clip one end of the metal strap to the connector, position the strap over the top of the relay, and clip the remaining end to the opposite side of the connector.
