Manufacturer: Mitsubishi Electric
Product No.: FR-A840-06100-2-60
Country of origin:United States
Product Type: Variable Frequency Drives
Payment: T/T, Western Union
Weight: 170000g
Shipping port: Xiamen
Warranty: 12 months
Executing high-capacity motor control in demanding industrial environments, the Mitsubishi Electric FR-A840-06100-2-60 is a high-performance variable frequency drive designed for the FR-A800 series architecture. This 400V class inverter is engineered with a Super Light Duty (SLD) rating of 610A, making it highly suitable for large-scale pumps, fans, and heavy-duty industrial machinery. The unit features built-in protective circuit board coating (3C2) to resist atmospheric contaminants and humidity, ensuring long-term operational reliability in harsh industrial conditions. It is configured as a standard model without plated conductors, prioritizing robust electrical performance and structural integrity in centralized motor control centers.
| Parameter | Specification Value |
|---|---|
| Manufacturer | Mitsubishi Electric |
| Model Code | FR-A840-06100-2-60 |
| Series | FR-A800 |
| Voltage Class | 400V Class (Three-Phase Input) |
| SLD Rated Current | 610 A |
| Conformal Coating | Yes (IEC 60721-3-3 3C2 compliant) |
| Plated Conductor | Without |
| Structure / Type | Standard Model (-2) / CA Type |
| Shipping Weight | 170 kg |
This model replaces older FR-A740 series configurations of equivalent capacity. When migrating from the A700 series, verify panel mounting dimensions and control terminal wiring differences. Parameter configurations can be imported and converted using the FR-Configurator2 software utility to maintain application logic compatibility.
With a high unit weight of 170 kg, mechanical installation requires dedicated lifting lugs and structures rated for the load. Ensure the installation enclosure is designed for the high thermal dissipation profile of a 610A SLD drive. Maintain standard clearance guidelines above and below the drive to facilitate proper airflow through the cooling heatsinks. Do not block the intake or exhaust paths.
Always use symmetrical, shielded motor cables to prevent electromagnetic interference (EMI) issues with nearby low-voltage instrument signals. Connect the grounding terminals directly to the system's common ground busbar using short, heavy-gauge cables. Prior to initial power-up, verify that the motor thermal overload parameter (Pr. 9) is matched to the actual connected motor nameplate full-load current to prevent motor damage during high-load operations.
Risk of electrical shock or arc flash. Disconnect and lock out all input power sources prior to starting installation, wiring, or maintenance procedures. After power is disconnected, wait at least 10 minutes for the internal bus capacitors to discharge fully, and verify zero voltage on the DC bus terminals before touching any internal electrical connections.
