Mitsubishi Electric FX3UC-96MT/D FX3UC Series PLC CPU Unit

SKU FX3UC-96MT/D

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Mitsubishi Electric

  • Product No.: FX3UC-96MT/D

  • Country of origin:United States

  • Product Type: PLC CPU Units

  • Payment: T/T, Western Union

  • Weight: 1500g

  • Dimensions: 85.4 mm x 90.0 mm x 74.0 mm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

Designed to maximize operational efficiency within tight control cabinets, the FX3UC-96MT/D represents a high-density processing solution in the MELSEC FX3UC series. This PLC CPU unit incorporates substantial local digital I/O capabilities and fast execution times, allowing control engineers to execute complex sequencing in a compact footprint. By utilizing high-density connector interfaces instead of traditional terminal blocks, the system significantly minimizes cabinet space requirements while optimizing harness installation. The CPU contains a robust internal processing engine capable of running extensive sequential control, positioning, and analog processing tasks simultaneously.

Features

  • Ultra-Compact Footprint: Ideal for space-constrained installations, providing high-density I/O integration.
  • High-Speed Processing: Achieves execution speeds of 0.065 microseconds per basic instruction.
  • Substantial Memory Capacity: Built-in EEPROM program memory capable of storing up to 64,000 steps of application code.
  • High-Density Connector Interfaces: Uses MIL-style connectors for quick, secure wiring harnesses and reduced physical size.
  • Built-in Positioning: Integrates high-speed counters and pulse outputs for independent axis control configurations.

Applications

  • High-speed OEM packaging machines
  • Automated assembly systems and electronics manufacturing
  • Material handling and conveyor line sorting
  • Multi-axis positioning systems
  • Compact distributed control configurations in process plants

Technical Specifications

CategoryTechnical ParameterValue
Manufacturer Mitsubishi Electric
Model / Part Number FX3UC-96MT/D
Series Name FX3UC Series
Product Type PLC Main Unit / CPU Unit
Input Voltage 24 VDC
Integrated Inputs 48 (24 VDC, Sink type)
Integrated Outputs 48 (Transistor, Sink type)
Total Onboard I/O Points 96
Program Memory Capacity 64,000 Steps (Built-in EEPROM)
Instruction Execution Time 0.065 microseconds (Basic instruction)
Connection Type Ribbon Connector (MIL-C-83503 standard)
Dimensions (W x H x D) 85.4 mm x 90.0 mm x 74.0 mm
Shipping Weight 1.5 kg

Installation Guidelines

  • DIN Rail Mounting: Snap securely onto a standard 35 mm DIN rail. Ensure the DIN rail mounting hook is fully engaged.
  • Thermal Management: Maintain a minimum clearance of 50 mm above and below the CPU unit to allow for natural convection cooling.
  • Wiring Safety: Power down the 24 VDC distribution loop completely before inserting or removing the MIL-style I/O connectors.
  • Grounding: Connect the functional ground terminal to a low-impedance ground point using a wire of at least 2 square millimeters.

Compliance and Certifications

  • CE (Electromagnetic Compatibility Directive)
  • UL / cUL Listed

FAQ

What type of connections are used for the I/O terminals on the FX3UC-96MT/D?

The FX3UC-96MT/D utilizes high-density MIL-C-83503 compatible ribbon cable connectors instead of traditional terminal blocks to minimize physical footprint.

Does this CPU unit require an external memory cassette?

No, the FX3UC-96MT/D features a built-in internal EEPROM memory with a capacity of up to 64,000 steps, making an external cassette optional.

What is the polarity of the integrated transistor outputs?

The integrated transistor outputs on the FX3UC-96MT/D are sink type (NPN).

What is the nominal input voltage range for this PLC CPU?

The module operates on a standard nominal input voltage of 24 VDC.
