Omron CS1W-PDC55 CS-Series Process Analog I/O Module

SKU CS1W-PDC55

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Omron
Product No.: CS1W-PDC55
Country of origin:Japan
Product Type: Process Analog I/O Units
Payment: T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

Engineered for high-accuracy industrial process automation, the CS1W-PDC55 functions as a high-density, isolated process analog input module within the Sysmac CS-series PLC platform. This module provides reliable multi-channel analog measurement, translating raw field signals from sensors, transmitters, and transducers into precise digital values for the PLC CPU. Designed for robust deployment in demanding control environments, the CS1W-PDC55 process analog input unit features high electrical isolation and noise immunity to maintain loop integrity across complex automation architectures.

Features

Supports up to 8 isolated analog input channels for versatile field instrument integration.
Direct backplane installation on CS-series racks for simplified system architecture and high-speed data exchange.
Removable screw terminal blocks simplify wiring and maintenance procedures.
Robust channel-to-channel isolation safeguards the control system against common-mode noise and ground loops.
Synchronous operational compatibility with standard CS-series CPU units.

Applications

Water and wastewater treatment processing
Chemical and petrochemical processing plants
HVAC and industrial climate control systems
Power plant control systems and auxiliary loops
Continuous emissions monitoring systems (CEMS)

Technical Specifications

Manufacturer	Omron
Part Number / Model	CS1W-PDC55
Series	Sysmac CS-Series
Module Type	Process Analog I/O Unit
Number of Inputs	8 Channels
Input Type	Analog
Termination Style	Screw Terminal Block
Mounting Type	Backplane / Rack Mount
Operating Temperature	0 to 55 degC

Installation Guidelines

Ensure the rack power supply is completely switched off before mounting or removing the CS1W-PDC55 from the backplane. Route all analog signal wires in separate conduits from high-voltage AC power cabling to minimize electromagnetic interference. Always connect the functional ground terminal on the PLC rack to a dedicated, low-impedance ground point to ensure maximum measurement accuracy and noise mitigation.

FAQ

What is the main function of the Omron CS1W-PDC55 module?

The Omron CS1W-PDC55 is an isolated process analog input module designed for CS-series PLC racks, allowing high-precision measurement of up to 8 field analog signals.

What connection terminal type does the CS1W-PDC55 use?

This module uses integrated screw terminals for secure, reliable field wiring.

What is the operating temperature range for this process analog unit?

The CS1W-PDC55 has an operating temperature range of 0 to 55 degC.

How is the CS1W-PDC55 module mounted?

It mounts directly onto a compatible CS-series PLC backplane / rack assembly.
