Omron F3SJ-E0185P25 F3SJ Series Safety Light Curtain

Only 6 item(s) left in stock

Manufacturer: Omron
Product No.: F3SJ-E0185P25
Country of origin:Japan
Product Type: Safety Light Curtains
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months

Description

Designed to secure hazardous machinery spaces, the Omron F3SJ-E0185P25 offers reliable hand detection with a 25-mm resolution. This Type 4 safety light curtain streamlines machine safeguarding by providing standard PNP outputs and a compact protective height of 185 mm. Operating on a stable 24 VDC SELV/PELV power supply, it integrates into machine control systems requiring optoelectronic presence detection. Its durable construction and simple alignment indicators make it an efficient solution for basic safety barrier installations.

Features

Type 4 safety sensor configuration optimized for hand protection applications.
Provides a 185 mm protective height with 8 precisely aligned beams.
Built-in PNP output design for direct connection to safety controllers and PLCs.
Infrared LED emitter with an operating range of up to 7 meters.
IP65 ingress protection rating suitable for damp or dusty industrial environments.

Applications

Robotic work cell safeguarding.
Packaging machinery and conveyor systems.
Assembly lines and pick-and-place stations.
Material handling and sorting systems.

Technical Specifications

Manufacturer	Omron
Part Number / Model	F3SJ-E0185P25
Sensor Type	Type 4 Safety Light Curtain
Protective Height	185 mm
Detection Capability	25 mm diameter
Number of Beams	8
Beam Gap	20 mm
Operating Range	0.2 m to 7.0 m
Output Type	PNP
Power Supply Voltage	24 VDC (SELV/PELV) +/-20% (ripple p-p 10% max.)
Emitter Current Consumption	41 mA max. (at 8 beams)
Receiver Current Consumption	42 mA max. (at 8 beams)
Light Source (Wavelength)	Infrared LED (870 nm)
Degree of Protection	IP65
Weight	1.0 kg

Installation Guidelines

Ensure the calculated safety distance to the hazardous area complies with local standards (e.g., ISO 13855) based on the machine response time and the light curtain's response time.
Mount the emitter and receiver securely on a rigid, vibration-free structure to maintain optical alignment over the operating range.
Route transmitter and receiver cables separately from high-voltage or high-noise power lines to prevent signal interference.
Connect to a verified SELV/PELV 24 VDC power supply to ensure electrical isolation safety.

Key Features:

#Omron F3SJ Series #Safety Light Curtains

What is the detection capability of the F3SJ-E0185P25 safety light curtain?

The F3SJ-E0185P25 has a 25-mm diameter detection capability, which is designed for reliable hand protection.

What is the maximum operating range for this safety barrier?

This light curtain features an operating range of 0.2 meters to 7.0 meters.

What type of outputs are available on this model?

The Omron F3SJ-E0185P25 provides standard PNP safety outputs.

What is the ingress protection rating of this unit?

The safety light curtain is IP65 rated, protecting it against dust ingress and low-pressure water jets.
