Omron NS5-SQ00-ECV2 NS Series Interactive Display Panel

Description

Designed for robust machine-to-operator visualization, the Omron NS5-SQ00-ECV2 serves as a high-reliability interactive display panel within the Sysmac automation platform. This human-machine interface (HMI) provides clear graphical monitoring and touch-input control, allowing operators to interact directly with PLC-driven machinery. Engineered to operate efficiently under demanding factory floor conditions, it minimizes cabinet space requirements while delivering reliable visual diagnostics and operational oversight.

The unit features a 5.7-inch color display interface optimized for real-time data representation and parameter modification. With versatile serial and host-link communication capabilities, the module integrates into standard industrial control architectures, ensuring continuous communication with controller units without signal latency.

Features

• 5.7-inch high-visibility color screen for clear graphical visualization of machinery states.
• Analog resistive touch screen allowing precise operator inputs and menu navigation.
• Built-in backup battery designed for long-term memory protection of critical variables.
• Low power-loss design, operating efficiently on standard industrial 24 VDC power lines.
• Robust housing suitable for integration into sealed electrical enclosures.

Applications

• Automotive assembly lines and conveyor monitoring.
• Packaging and labeling machine control interfaces.
• Water and wastewater municipal treatment plant control panels.
• Food and beverage thermal processing lines.

Technical Specifications

Installation Guidelines

Prior to panel mounting, ensure the cutout dimensions match the engineering drawing specifications for the 5.7-inch NS5 enclosure. Mount the unit securely using the provided fixing brackets to maintain the specified ingress protection rating. Route all 24 VDC power cables away from high-voltage AC motor lines to prevent electromagnetic interference. Connect the functional ground (FG) terminal directly to a low-impedance grounding point (100 ohms or less) to ensure stable communication and noise immunity.
