Schneider Altistart 22 ATS22C41S6U Soft Starter

SKU ATS22C41S6U

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Schneider Electric
Product No.: ATS22C41S6U
Country of origin:France
Product Type: Soft starters
Payment: T/T, Western Union
Weight: 27750g
Dimensions: 37cm x 55cm x 49cm
Shipping port: Xiamen
Warranty: 12 months

Description

The ATS22C41S6U is a Soft Starter from the Altistart 22 range, designed by Schneider Electric for the controlled starting and stopping of three-phase asynchronous motors. This unit is rated for a nominal current of 410 A and supports a wide supply voltage range from 208V to 600V. It provides effective torque management, reducing mechanical stress on motor-driven systems such as pumps, fans, and compressors during acceleration and deceleration phases.

Features

Integrated bypass contactor for reduced heat dissipation and energy efficiency
Supports a wide operating voltage range (208V to 600V)
Designed for optimized starting performance of asynchronous motors
Compact configuration for high-power applications (125-350 HP)

Applications

Centrifugal pumps
Axial and centrifugal fans
Compressors
Conveyors and material handling equipment

Technical Specifications

Feature	Specification
Manufacturer	Schneider Electric
Range	Altistart
Subrange	22
Model	ATS22C41S6U
Product Type	Soft starters
Nominal Current	410 A
Supply Voltage	208-600V
Power Rating	125-350 HP
Weight	27.75kg
Dimensions	37cm x 55cm x 49cm
Commodity Code	84798997
PLM Product Status	Active

Installation Guidelines

Mounting: Ensure the unit is mounted vertically in an enclosure with adequate ventilation to dissipate heat generated during operation.
Wiring: Connect the power supply to the input terminals and the motor to the output terminals as indicated on the connection diagram. Ensure proper conductor sizing for the 410 A current rating.
Grounding: Secure a reliable protective earth connection to the chassis to ensure safe operation and electromagnetic compatibility.
Environment: Install in a location protected from excessive dust, humidity, and corrosive atmosphere to maintain long-term reliability.

FAQ

What is the primary function of the ATS22C41S6U soft starter?

This unit is designed to provide smooth acceleration and deceleration for three-phase asynchronous motors, reducing mechanical and electrical stress.

What is the rated current for this device?

The nominal current rating for the ATS22C41S6U is 410 A.

Does this model support an integrated bypass?

Yes, the Altistart 22 range features an integrated bypass contactor to improve energy efficiency and reduce heat.
