Schneider Altivar ATV16U41M2 Variable Frequency Drive

Description

The ATV16U41M2 is a Variable Frequency Drive (VFD) from the Altivar series, engineered to provide precise speed and torque control for industrial three-phase motors. With a power rating of 2.2 kW (3 HP) and an operating voltage range of 208/240V, this drive is optimized for applications requiring energy efficiency and improved mechanical reliability. Designed for standard industrial frequencies of 50-60 Hz, the ATV16U41M2 supports an operational current between 10 A and 14 A, making it a versatile component for managing pump, fan, and conveyor motor performance.

Features

• Optimized motor speed and torque control
• Compatible with 208/240V power supplies
• Supports both 50 Hz and 60 Hz line frequencies
• Designed to reduce mechanical stress and improve energy efficiency
• Compact design suitable for standard control cabinet integration

Applications

• Pumping systems and fluid transfer
• HVAC fan and blower control
• Conveyor and material handling systems
• Centrifugal machinery
• General-purpose industrial motor speed management

Technical Specifications

Installation Guidelines

• Mounting: Ensure the VFD is mounted vertically in a clean, ventilated enclosure to allow for proper airflow and heat dissipation.
• Wiring: Use shielded cabling for motor connections to prevent electromagnetic interference (EMI). Ensure that input power is fused according to local electrical codes.
• Grounding: Connect the drive to a reliable plant earth ground to ensure safe operation and electromagnetic compatibility.
• Environment: Keep the drive in a dry location free from corrosive gases, excessive vibration, and high ambient temperatures.
• Maintenance: As an obsolete product, ensure all spare components are stored in climate-controlled environments and handled using ESD-safe procedures.
