Schneider Electric Altistart 46 ATS46M10N Soft Starter

Description

The ATS46M10N is a high-capacity Altistart 46 soft starter designed for large-scale industrial motor control applications. Capable of handling a nominal current of 1000 A, this unit provides controlled acceleration and deceleration for three-phase asynchronous motors. By regulating the voltage applied to the motor, the ATS46M10N minimizes mechanical shocks to drive trains and reduces excessive inrush current, thereby extending the operational lifespan of both the motor and associated mechanical equipment. This model represents the robust, reliable engineering typical of the Altistart 46 range, optimized for high-power demands.

Features

• Motor Control: Controlled starting and stopping for high-power three-phase motors
• Current Rating: 1000 A nominal
• Performance: Reduces inrush current and mechanical stress
• Application-Specific: Ideal for high-inertia loads and heavy-duty industrial machinery
• Construction: Robust design for industrial integration

Applications

• Large-scale pump and fan systems
• Industrial centrifugal compressors
• High-inertia conveyer systems
• Heavy-duty manufacturing crushers and mills
• Large ventilation and air extraction systems

Technical Specifications

Installation Guidelines

• Mounting: Due to the weight of 45 kg, ensure the mounting structure is reinforced and capable of supporting the unit securely. Install vertically in a well-ventilated enclosure.
• Environment: Maintain an operating environment free from conductive dust, moisture, and extreme temperatures. Adequate cooling air circulation is vital for high-current components.
• Wiring: Use busbars or large-gauge cables rated for 1000 A. Ensure all termination points are tightened according to the technical documentation to prevent localized heating.
• Safety: Always disconnect all power sources before inspection or maintenance. Ensure the unit is properly grounded to a main system earth bus.
• Integration: Verify that the supply mains are capable of supporting the required starting current profiles before commissioning the drive.
