Schneider Electric ATV21HD15N4 Altivar 21 Variable Frequency Drive

Description

The ATV21HD15N4 is a Schneider Electric Altivar 21 variable frequency drive (VFD) designed for precise motor control in industrial applications. This drive provides a power rating of 15 kW (20 HP) and is engineered for operation with 480 V supply voltages. It features an integrated class A EMC filter to minimize electromagnetic interference, ensuring reliable operation in standard industrial electrical environments. The unit is housed in an IP20-rated enclosure, intended for mounting within protected electrical cabinets or control panels.

Features

• Series: Altivar 21
• Power Rating: 15 kW / 20 HP
• Input Voltage: 480 V
• EMC Compatibility: Integrated class A EMC filter
• Protection Rating: IP20

Applications

• HVAC systems and building automation
• Pump and fan control
• Conveyor systems
• Industrial process machinery
• Centrifugal compressor control

Technical Specifications

Installation Guidelines

• Mounting: Install the drive in a vertical position inside a control panel. Ensure adequate spacing around the unit for proper heat dissipation.
• Environment: The installation location must be clean, dry, and protected from excessive dust, corrosive gases, and moisture. Ensure the operating ambient temperature is within specifications.
• Wiring: Connect the 3-phase power supply and motor leads securely. Use shielded cabling for motor connections to ensure compliance with the integrated EMC filter standards.
• Grounding: Establish a solid ground connection from the drive chassis to the system ground bus to prevent electrical noise and ensure operator safety.
• Ventilation: Ensure that the cabinet has adequate air intake and exhaust. If installed in a closed cabinet, supplemental cooling (fans) may be required to maintain performance.
