Description

The ATV340U22N4E is an Altivar 340 series variable frequency drive (VFD) designed for high-performance motor control in industrial automation. This three-phase controller supports a power rating of 2.2 kW and operates at 400 V. Equipped with integrated Ethernet connectivity, the ATV340U22N4E enables seamless integration into modern industrial communication networks for real-time monitoring, diagnostics, and precise control of electrical motors. It is engineered for demanding industrial environments where reliability, high-speed response, and efficiency are critical for production processes.

Features

• Integrated Ethernet communication for advanced network connectivity
• Supports three-phase 400 V power supply
• Power capacity of 2.2 kW for efficient motor regulation
• Engineered for rapid control and high-performance automation
• Compact, robust design suitable for space-constrained control cabinets

Applications

• High-speed manufacturing machinery
• Packaging and material handling systems
• Complex motion control applications
• Industrial conveyor and processing lines
• Automated assembly machinery

Technical Specifications

Installation Guidelines

• Mounting: Install vertically within an industrial enclosure to facilitate adequate airflow across the heatsink.
• Cooling: Ensure sufficient clearance is maintained around the unit to prevent thermal overload during continuous high-load operation.
• Ethernet: Use high-quality shielded Ethernet cabling to maintain network signal integrity and minimize EMI.
• Grounding: Establish a low-impedance ground connection for both the drive and the motor chassis to ensure safety and electromagnetic compatibility.
• Cable Routing: Separate power cables from Ethernet and control signal cables to prevent data corruption and interference.
